Page 233 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

HEAVY DUTY OIL ACCUMULATORS ACCUSUMP PRO ELECTRIC
PRESSURE CONTROL VALVING
The convenience of an electric valve with the
rapid refill of a manual valve. The Accusump Pro
will discharge oil when oil pressure drops below
the pre-set rating and only refill when the pressure
rises above the setting. Includes electric control valve,
CAN24-006
SURGE PROTECTION toggle switch, wire and terminals.
Accusump Oil Accumulators provide an extra margin of protection against Part No. Description
engine damage caused by lack of oil pressure. As the oil in the pan sloshes, CAN24-271X E.P.C. Valving Kit, 20-25 PSI Discharge/Refill
the pickup can become uncovered, causing a loss of oil pressure. The Canton CAN24-273X E.P.C. Valving Kit, 35-40 PSI Discharge/Refill
Accusump provides oil during these times, reducing the chance of damage.
PRE-OILING CHECK VALVE CAN24-280
Research indicates the majority of wear occurs during start-up, before oil Check valve insures that oil being discharged from Ac-
pressure is established. The Accusump delivers oil under pressure before your cusump lubricates the engine bearings and is not fed back
engine is spun over. to the pump. A must in systems where a remote filter or
PRECISION CONSTRUCTION cooler is used. 1/2" NPT inlet and outlet.
Built from 4-1/4" dia. aluminum tube with a roller burnished, PTFE coated
inside, double O-ring piston, screw-in aluminum end caps, air pressure gauge, CHEVY STORAGE PLATES CAN84-100
air pre-charge valve, safety blow-off and a manual or electric valve. A secure method for
MANUAL OR ELECTRIC OPERATION VALVES sealing exhaust ports dur-
The manual valve provides positive control and can be mounted on the Ac- ing engine storage. Bolts
cusump or in the feed line. The electric control valve simplifies the operation of to small block Chevy with
the Accusump and can provide automatic pre-oiling when tied into the ignition standard exhaust pattern.
switch. The electric valve units are ideal in applications where it is difficult to Sold in pairs.
access a manual valve.
CHEVY UNIVERSAL ALTERNATOR
3 QT. ACCUSUMP CAN24-006 MOUNTING BRACKET
16" long, 4-1/4" dia. Accusump is recommended for large cubic inch engines CAN75-220
or when severe oil pressure fluctuation problems are experienced. Manual or Gold anodized billet aluminum bracket
electric valve kit sold separately. is compatible with GM, Honda, ND or
Mitsubishi alternators. Positions the
2 QT. ACCUSUMP CAN24-026 alternator to the right side of the wa- ter
12" long, 4-1/4" dia. Accusump is recommende d for surge control on small pump and includes hardware.
block V-8, V-6 and 4 cylinder engines. Ideal for use in applications where
mounting space is restricted. Manual or electric valve kit sold separately.
WATER PUMP
MOUNTING CLAMPS MOUNTED DRIVE PULLEY
CAN24-200 CAN75-280
Stainless steel, T-clamp mounting brackets will An excellent way to add an extra drive pulley. 3-3/4"
mount all 4-1/4" Accusumps.
diameter drive pulley mounts on the front of the water
pump pulley and can be used to drive the power steering
pump or alternator. Works with 5/8" or 3/4" shaft water
ACCUSUMP pumps.
MANUAL VALVE KIT
CAN24-260 FAN SPACERS
Manual Accusump ball valve has 1/2" NPT fittings and a pipe nipple. Durable spacers are
machined from billet alu-
ACCUSUMP PRO ELECTRIC VALVE KIT minum to fit Chevy or Ford
CAN24-270X water pumps. Fasteners
and adapter bushing for
Electric valve kit is useful when the Accusump 5/8" and 3/4" water pump
is mounted in a hard-to-reach location or where a shafts are included.
manual valve is not practical. When wired directly to the Part No. CAN75-610 CAN75-625
Description
ignition switch, the Accusump automatically acti-
vates when switch is on to provide pre-oiling. CAN75-610 1" Fan Spacer
All manual Accusumps with 1/2" NPT can CAN75-615 1-1/2" Fan Spacer
be converted. Kit includes electric control CAN75-620 2" Fan Spacer
valve, toggle switch, wire and terminals. CAN75-625 2-1/2" Fan Spacer
CAN75-630 3" Fan Spacer

232
