COOLING

PLASTIC TANK RADIATORS ALUMINUM TANK RADIATORS
Uniquely designed plastic tank radiators with aluminum core offer over a Excellent quality at an affordable price. Filler necks ar e machined, not
22% gross weight savings to comparable aluminum tank radiators when filled stamped, and tanks are furnace brazed, not epoxied, eliminating two prime
with coolant. These performance radiators also provide 6% better cooling than sources of leakage. The lightweight 1" tubes, arranged in two rows, offer
aluminum tank radiators. Tanks are fastened to the core with multi-clamps and outstanding cooling in race cars, off-road vehicles and street machines. Width
an o-ring gasket, a process similar in design to many of today’s high perfor- listed is overall, including tanks.
mance late model muscle cars. Corrosion resistant tanks have molded in 1-1/2"
inlet and 1-3/4" beaded hose outlets. Widths are overall including tanks. SINGLE PASS
• LIGHTWEIGHT DESIGN 1-1/2" inlets and 1-3/4" outlets have
• 22% WEIGHT SAVINGS beaded hose fittings.
Part No. Description
• 6% BETTER COOLING GM
• CORROSION RESISTANT ALL30010 19" x 22"
ALL30011 19" x 24"
ALL30012 19" x 26" ALL30012
SINGLE PASS ALL30014 19" x 28"
Part No. Description ALL30016 19" x 31"
GM ALL30042 16" x 28"
ALL30050 19" x 22" Ford/Chrysler
ALL30020
19" x 22"
ALL30051 19" x 24" ALL30021 19" x 24"
ALL30052 19" x 26" ALL30022 19" x 26"
ALL30053 19" x 28" ALL30024 19" x 28"
ALL30054 19" x 31" ALL30052 ALL30026 19" x 31"
ALL30043 16" x 28"
ALL30022
DUAL PASS
Part No. Description Dual pass radiators circulate coolant
Ford/Chrysler across the top half of the radiator, then
ALL30320 19" x 22" back across the bottom half, allowing
ALL30321 19" x 24" up to twice the heat dissipation. 1-3/4"
ALL30322 19" x 26" outlet. The universal inlet design ac-
ALL30324 19" x 28" cepts 1-1/2" standard hose, 1-3/4" hose,
ALL30326 19" x 31" -16 or -20AN fittings (sold separately).
ALL30322 Part No. Description
ALL30033 19" x 24" ALL30035
ALL30035 19" x 26"
ALL30036 19" x 28"
ALL30037 19" x 31"
DUAL PASS Radiator Inlet Fittings
Part No. Description ALL30038 1-1/2" Hose Fitting
ALL30056 19" x 24" ALL30041 1-3/4" Hose Fitting
ALL30057 19" x 26" ALL30039 -16AN Fitting
ALL30058 19" x 28" ALL30040 -20AN Fitting
ALL30059 19" x 31"
TRIPLE PASS
ALL30057 Triple pass radiators circulate cool-
ant across the top portion of the radia-
tor, back across the mid-section and
through the bottom allowing maximum
heat dissipation. Standard 1-3/4" outlet
and a universal inlet designed to accept
Radiators with plastic tanks are designed to use radiator caps rated at 22 lbs. 1-1/2" standard hose, 1-3/4" hose, -16
or less. Radiators with aluminum tanks are designed to use radiator caps rated or -20AN fittings (sold separately).
at 25 lbs. or less. Part No. Description ALL30046
ALL30045 19" x 24"
ALL30046 19" x 26"
ALL30047 19" x 28"
ALL30048 19" x 31"
Radiator Inlet Fittings
ALL30038 1-1/2" Hose Fitting
ALL30041 1-3/4" Hose Fitting
ALL30039 -16AN Fitting
ALL30040 -20AN Fitting
