Page 413 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

FORGED STEEL CRANKSHAFTS FORGED BILLET H-BEAM
CONNECTING RODS
Forged series 4340 steel connecting rods are core hardened
to increase tensile strength and mag-particle inspected. Rods
are fitted with ARP fasteners and finish honed. Center-to-center
dimensions are held within +/-.001" and journals are honed to
+/-.0001". All rods listed below are bushed for full floating wrist
pins. Offered with choice of standard 3640 or premium ARP
Crankshafts are constructed from 4340 steel and undergo core hardening for 2000 fasteners. Sold in sets of eight.
added durability and mag-particle inspection for superior quality control.
Housing Big End Pin End Bolt Gram
Main Rod Part No. Description Bore Pin Width Width Size Weight
Part No. Description Stroke Journal Journal Flange Weight SB Chevy
K1T012DAD348 SB Chevy 3.480" 2.450" 2.100" 6-Bolt 53 lbs. K1T012AD25570 5.700" 2.225" .927" .940" 1.010" 7/16" 622
K1T011DAI340 SB Ford 3.400" 2.250" 2.100" 6-Bolt 47 lbs. SB Chevy
K1T012AD25600 2.225" .927" .940" 1.010" 7/16" 635
6.000"

JEFF VRSEK MIKE DAMIC
CHROME CHROME
14" DIA. DROP BASE 14" DIA. RAISED BASE
AIR CLEANER ASSEMBLIES AIR CLEANER ASSEMBLIES
Race ready, low profile air cleaners drop air filter Elevate the filter element 9/16" above carburetor
7/8" or 1-1/4" below carburetor flange and fit carbu- flange for GM HEI clearance, or where hood clear-
retors with 5-1/8" necks. High flow, 14" element, base ance is not a concern. High flow, 14" dia. element,
and top lid are included. base and top are included.
Drop Element Total Element
Part No. Description Base Height Height Part No. Description Raise Base Height Total Height
KNE60-1280 14" Dia. Chrome Assembly 1-1/4" 3" 2-3/4" KNE60-1264 14" Dia. Chrome Assembly 9/16" 3" 4-5/8"
KNE60-1290 14" Dia. Chrome Assembly 1-1/4" 4" 3-3/4" KNE60-1260 14" Dia. Chrome Assembly 9/16" 4" 5-5/8"
KNE60-1300 14" Dia. Chrome Assembly 1-1/4" 5" 4-3/4" KNE60-1270 14" Dia. Chrome Assembly 9/16" 5" 6-5/8"
KNE60-1310 14" Dia. Chrome Assembly 1-1/4" 6" 5-3/4"
KNE60-1430 14" Dia. Chrome Assembly 7/8" 3" 3-1/8"
KNE60-1440 14" Dia. Chrome Assembly 7/8" 4" 4-1/8"

X-STREAM AIR CLEANER AIR CLEANER
ASSEMBLIES ASSEMBLIES
High flow air filter elements and steel bases Here’s the answer for all racers looking for
are topped by the X-Stream Air Flow Top Plate bolt-on horsepower. Flow Control provides
to boost horsepower and torque. Assemblies fit increased air flow and horsepower.
most popular carburetors with 5-1/8" dia. neck. Part No. Description
KNE61-2000 2BBL Holley, 14" x 4" With Choke Tower
Drop Element Total
Part No. Description Base Height Height KNE61-2010 2BBL Holley, 14" x 4.5" With Choke Tower
14" Dia. X-Stream KNE61-2020 2BBL Holley, 14" x 4" Without Choke Tower
KNE66-3040 1-1/4" 3" 2-3/4"
Assembly KNE61-2040 2BBL Rochester, 14" x 4.5"
14" Dia. X-Stream KNE61-4000 4BBL Holley, 14" x 4" Without Choke Tower
KNE66-3070 1-1/4" 5" 4-3/4"
Assembly KNE61-4020 4BBL Holley 390-800 CFM, 14" x 4" With Choke Tower
X-STREAM
AIR FLOW TOP PLATE
KNE66-1401
Filter/plate replaces standard 14" air
cleaner top plate to increase airflow for
horsepower and torque gains. The perfect
companion to the K&N Air Filter Element.

RYAN SUTTER
