BELT DRIVE TANDEMX PUMP KITS HTD SINGLE BELT DRIVE KITS
Complete packaged Belt Drive TandemX Designed for modifieds that use a KSE tandem drive pump
Pump kits, available in engine or with a V-belt driven water pump, front mount kit includes
bellhousing mounted versions, crank mandrel, crank mandrel bolt, double groove 20T
include all of the necessary crank pulley, crank pulley, guide, spacer, end cap,
components and hardware 40T pump drive pulley and serpentine belt. Water
for installation. Direct head mount kit pump pulley and bolts are not included.
is engineered for Chevy “604” crate or traditional small block Chevy applica- Part No. Description
tions, offering an optimized drive kit for improved power steering assist that Tandem Pump HTD Drive Kit, SB Chevy,
works with gasoline or alcohol applications. Bellhousing mounted kit delivers KSEKSD1025 Use KSEKSC1056 Mounting Bracket
a clean and simple TandemX pump setup to modifieds or late models that are Tandem Pump HTD Drive Kit, “604” Crate,
fitted with a Bert/Brinn style bellhousing. Kits are sold complete with TandemX KSEKSD1026 Use KSEKSC1060 Mounting Bracket
pump, mounting kit, bypass fuel regulator, belt drive kit and all hardware.
Related Components
Part No. Description KSEKSD1015-270 Crank Mandrel
KSEKSC2020-002 SB Chevy/"604” Crate Engine Mount Kit
KSEKSC2021-002 Bert/Brinn Bellhousing Mount Kit KSEKSD1016 Spacer
KSEKSD1017 HTD Pulley, 20T
BELT DRIVE TANDEMX PUMPS KSEKSD1019 HTD Pulley, 40T
Fully redesigned TandemX pump offers increased perfor- KSEKSD1020 Belt Guide
mance and over 25% reduced weight. Combined positive KSEKSD1021 End Cap
displacement power steering and fuel pump is KSEKSD1061 Pulley Guides, 40T Pulley, Pair
driven by a single shaft, reducing weight, while KSEKSD1062 HTD Pulley, 44T
increasing mechanical efficiency and simplifying KSEKSD1063 Pulley Guides, 44T Pulley, Pair
plumbing. The gerotor pump has a high alloy, 5/8" Note: A 4-3/4" long crankshaft mandrel bolt is required.
diameter heat treated shaft with 1/8" keyway, heavy
duty front ball bearing, bi-metal central journal
bearing and a billet aluminum body and separators. 700 SERIES FAST RATIO SPORTSMAN
Part No. Description POWER STEERING BOX
TandemX Pump, Designed For Applications Fast ratio, Sportsman Power Steering Box simplifies
KSEKSC1064-002 With Up To 700 HP, Modifieds And Crate Late Models, circle track steering systems, eliminating the need
Alcohol And All Gas for a steering quickener. The 700 Series steering box,
TandemX Pump, Designed For Applications
KSEKSC1064-004 which consists of a remanufactured OEM 3-bolt
With Over 700 HP, Late Models, Alcohol Only housing with refinished internal components, billet
KSEKSC1056 SB Chevy Mounting Kit aluminum side cover and bottom plate, delivers
KSEKSC1059 Bert/Brinn Bellhousing Mounting Kit
increased driver feel and response. Legal in all modified
DIRECT DRIVE TANDEMX PUMPS sanctioning bodies. Sold complete with -6AN JIC fittings. Choose from boxes
with 6:1 or 8:1 ratio and 13/16"-36 or 3/4"-30 input spline.
Direct drive TandemX pumps, which are fully redesigned, Part No. Description
mount directly to dry sump oil pump. Pumps utilize 3/8" KSEKSG7061-185 700 Series Steering Box, .185" Valve/6:1 Ratio, 13/16"-36 Input
diameter heat treated hex shaft and include adapter KSEKSG7062-185 700 Series Steering Box, .185" Valve/6:1 Ratio, 3/4"-30 Input
shaft for easy installation. KSEKSG7081-210 700 Series Steering Box, .210" Valve/8:1 Ratio, 13/16"-36 Input
Part No. Description KSEKSG7082-210 700 Series Steering Box, .210" Valve/8:1 Ratio, 3/4"-30 Input
Direct Drive TandemX Pump,
KSEKSC1065-002 Alcohol Up To 700 HP/Gasoline
Up To 1,000 HP DUAL FILTER POWER STEERING FLUID
Direct Drive TandemX Pump, RESERVOIR KSEKSF2000-010M
KSEKSC1065-004* Alcohol Up To 1,000 HP
* Due to high flow rate, pump is not recommended for gasoline. Premium, billet aluminum Power Steering Fluid Reservoir
incorporates removable, dual stainless steel filter elements to
TANDEM/TANDEMX PUMP COMPONENTS protect pumps and components from contamination. May be
Part No. Description mounted with included firewall mounting bracket or available
KSEKSC1020 Mounting Separator Plate, Belt Drive Tandem Pump tube mounting kits.
KSEKSC1024 Belt Drive Separator, Belt Drive TandemX Pump Part No. Description
Fuel Bypass Valve Poppet, Fits All Belt Or Direct Drive KSEKSF2015-125 Reservoir Tube Mounting Kit, 1-1/4" Dia.
KSEKSC1029
Tandem/TandemX Pumps KSEKSF2015-150 Reservoir Tube Mounting Kit, 1-1/2" Dia.
KSEKSC1052B Seal Kit, Up To Serial No. 5266 (Most Popular)
TandemX Direct Mount Kit, Mounts Pump To SB Chevy Or
KSEKSC1060
“604" SB Chevy Crate Engine BILLET BYPASS
KSEKSC1076B Seal Kit, Serial No. 5267 And Up FUEL PRESSURE REGULATOR
KSEKSC1077B Seal Kit, For TandemX Pumps
KSEKSC2005
ELIXER RACING POWER STEERING FLUID Precision CNC-machined from billet aluminum, bypass style
KSE’s Elixer has a higher viscosity index, anti-foaming, anti- regulator is compatible with both gasoline and alcohol. Regula-
wear and anti-oxidation capabilities to minimize power fade, tor includes an adjustable idle jet and includes ORB ports.
lower corner speed assist loss and decrease heat build-up. Sold Fittings must be purchased separately.
Description
Part No.
in quart or gallon containers. KSEKSC1051 Fuel Bypass Return Fitting, -8AN ORB x -8AN JIC
1 Quart 1 Gallon KSEKSC3000 Fuel Regulator Rebuild Kit
Part No. Part No.
KSEKSM1086 KSEKSM1091
