Page 422 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

HEAD RESTRAINT PAD SEAT MOUNTING BRACKETS
KIR68HP211 Custom fabricated from lightweight aluminum, brackets help provide a truly
Designed specifically for 68/69 Series seats, 2" thick professional installation when installing a Kirkey racing seat.
black tweed cloth covered restraint offers increased Part No. Description
head protection. KIR99201 Rear Seat Mount, 45 Series Seat
KIR99202 Rear Seat Mount,
36, 39, 41 & 47 Series Seats
KIR99203 Floor Seat Mount, 45 Series Seat KIR99202
Floor Seat Mount, 36, 39, 41,
KIR99204
41V, 47, 70 & 71 Series Seats
Rear Seat Mount,
KIR99205 70 & 71 Series Seats
Rear Seat Mount, KIR99205
KIR99208
79, 88 & 89 Series Seats

30 SERIES STEEL BODY STREET STOCK OVAL TRACK
MONO-TUBE SHOCK ABSORBERS SHOCK ABSORBERS
Single adjustable, mono-tube shocks have four distinct rebound adjustments Koni’s GM and Ford Street Stock Shocks fit stock mounts and meet the rug-
to suit chassis set-up or track conditions. The 30 Series shocks feature induction ged de mands of oval track rac ing with heavy-duty racing valving and five way
hardened, chrome plated 9/16" piston rods, and each shock body has three re bound ad just ment. The re bound setting can con trol slight push and loose
grooves to accept a lightweight threaded coil-over sleeve (sold separately). conditions, and fine tune the chassis for existing track con di tions.
Mount in any position and use as coil-over or, non-coil-over. Year/Model Front Rear
Compression Rebound Minimum Maximum Buick
Part No. Valving Valving Length Length 1974-79
5" Stroke Shock Absorbers Apollo/Skylark KON8040-1087 KON8040-1088
KON30-5325 3 2-5 10.75" 15.75" 1970-87
KON30-5436 4 3-6 10.75" 15.75" Regal/Grand National KON8040-1087 KON8040-1088
6" Stroke Shock Absorbers Chevrolet
KON30-6325 3 2-5 12.25" 18.25" 1970-81 Camaro KON8040-1087 KON8040-1018
KON30-6436 4 3-6 12.25" 18.25" 1977-91
7" Stroke Shock Absorbers Caprice/Impala KON8040-1087 KON8040-1088
KON30-7325 3 2-5 12.75" 19.75" 1964-85
KON30-7436 4 3-6 12.75" 19.75" Chevelle/Malibu KON8040-1087 KON8040-1088
KON30-7499* 4 9-9 12.75" 19.75" 1970-87 Monte Carlo KON8040-1087 KON8040-1088
KON30-7647 6 4-7 12.75" 19.75" 1975-79 Nova KON8040-1087 KON8040-1088
9" Stroke Shock Absorbers Ford
KON30-9325 3 2-5 14.75" 23.75" 1979-93
KON30-9414 4 1-4 14.75" 23.75" Mustang (4 Cyl. Only) – KON8040-1026
KON30-9436 4 3-6 14.75" 23.75" Oldsmobile
* Spec. Shock absorber for ACT Late Model Series 1964-87 Cutlass KON8040-1087 KON8040-1088
1975-79 Omega KON8040-1087 KON8040-1088
2.5" COIL-OVER KIT Pontiac KON8040-1087 KON8040-1088
1970-81 Firebird
KON30-0000 1973-77 Grand Am KON8040-1087 KON8040-1088
Coil over kit is used with large top eye 30 1969-87 Gran Prix KON8040-1087 KON8040-1088
series dampers with 2.5" I.D. springs. 1978-81 LeMans KON8040-1087 KON8040-1088
1975-79 KON8040-1087 KON8040-1088
Ventura II/Phoenix

REPLACEMENT BEARING SHOCK ABSORBER SPECIFICATIONS
KON1425-50-00-13
Bearing has a 1" O.D. and 1/2" I.D., and fits all Koni 30 Series STREET STOCK OVAL TRACK
shock absorbers. Upper Lower Max. Min.
Part No. Mount Mount Length Length
KON8040-1018 Fork Pin 20-3/8" 12-7/16"
BUMP RUBBER KON72-34-48-000-0 KON8040-1026 Pin Eye 20-5/16" 12-3/8"
Cellular polyurethane bump rubber fits on the shock KON8040-1087 Pin Cross Bar 13-3/4" 8-7/8"
absorber and prevents the suspension from bottoming out. KON8040-1088 Fork I-Stud 21-1/8" 13-1/16"
Similar to a progressive spring, bump rubber resistance
increases as it is compressed providing controlled bottoming KONI PART NUMBER SYSTEM
of the suspension. Prevents internal shock damage caused
by metal-to-metal contact. Linear soft bump rubber is 25mm tall and fits shocks 30-53 2 THROUGH 5
with a 14mm rod dia.
Note: The non-tapered end of the bump rubber may be trimmed to increase Rebound Valve Range
shock travel, if desired. Series Stroke Compression
