Page 421 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

ECONOMY LAYBACK OVAL TRACK SEATS INTERMEDIATE
Seats are made of .125" thick aluminum and available in 10° 20° LAYBACK YOUTH SEAT
layback double rib support, 20° layback single rib support or Identical to the above 36 Series seat, but in a 14" version
20° layback double rib support models. Seat covers must be for youth drivers. Affordable, lightweight aluminum seat
purchased separately. features a 20° layback, scaled down design with
Seat Black Vinyl Cover lower rib supports and shoulder belt holes. Extra
Width Part No. Part No. thick, high-density foam on rib supports and bottom
Double Rib Support 20° Layback adds comfort and safety. Purchase black cloth cover
14.5" KIR09200 KIR09401 separately.
15.5" KIR09400 KIR09401
Seat
17.5" KIR09800 KIR09801 Width Part No. Black Cloth Cover
Part No.
Double Rib Support 10° Layback 14" KIR36100-C KIR36111-C
15.5" KIR19400 KIR09401
17.5" KIR19800 KIR09801
Single Rib Support 20° Layback
21" KIR20900 KIR20901
STANDARD CHILD/QUARTER MIDGET SEATS
20° LAYBACK ROAD RACE Child seat, designed for 1/4 midgets or other child racing
CONTAINMENT SEATS cars, is constructed from 5052 alloy and includes an 8°
Designed for entry level road racing applica- layback design. Seats are MIG welded for added strength,
tions, 71 Series containment seats feature a include reinforced head rest, cutouts for shoulder har-
20° layback design. Seats, which accommodate ness and submarine belt. Black cloth seat cover must be
all head and neck restraints, may be adjusted 1" purchased separately.
higher or 1" lower to suit individual driver require- Width Seat Only Black Cloth Cover
ments. Contoured and raised seat bottoms provide 10" KIR24900 KIR24901
maximum thigh support, while reinforced head sup- 11" KIR24100 KIR24101
ports provide increased safety. Lightweight aluminum 12" KIR24200 KIR24201
construction seats are available in sizes from 15" to 17". 13" KIR24300 KIR24301
Black cloth cover must be purchased separately.
Width Seat Black Cover HEAD AND SHOULDER
15" KIR71300 KIR71311 RESTRAINT KIT KIR98711S
16" KIR71500 KIR71511 Update an existing Kirkey seat to accept head and
17" KIR71700 KIR71711
shoulder restraint system. Retro-fit kit is manu-
factured from .100" thick, 5052 grade aluminum,
DELUXE 18° is padded with energy absorbing foam and
LAYBACK ROAD RACE available in short version only for confined
CONTAINMENT SEATS cockpits. Black cloth covers, brackets and
Deluxe, 45 Series Road Race Containment hardware are included.
Note: Complete kit must be used to be effective and the head restraint
Seats are manufactured from TIG-welded .100" cannot be used separately.
thick 5052 aluminum and are MIG-welded inside
for added strength. Seats, which accommodate all
head and neck restraints, include reinforced rib and Head Support
shoulder restraints. The vertically adjustable head Shoulder Support
restraint is symmetrically designed for unobstructed Leg Support
peripheral vision and maximum safety. High density,
energy absorbing padding delivers added safety and SEAT SIDE SUPPORTS
comfort. Black cloth cover must be purchased separately. Supports provide protection for legs and
Width Seat Black Cloth Cover shoulders under high G-forces and during an
15" KIR45300 KIR45341 accident. Covers must be purchased sepa-
16" KIR45500 KIR45541 rately. Designed for use with all Kirkey seats
17" KIR45700 KIR45741 except full containment models.
18" KIR45900 KIR45941 Black Vinyl Black Cloth Red Cloth
Cover Cover Cover
Description
Part No.
MOLDED FOAM SEAT INSERT KIT Head Supports Part No. Part No. Part No.
KIR99300 KIR00100 Right KIR00101 KIR00111 KIR00112
Do-it-yourself kit allows adding form fitting high-density KIR00200 Left KIR00201 KIR00211 KIR00212
padding to the bottom and lumbar of an existing seat, Leg Supports
increasing safety and comfort. Sold complete with all KIR00300 Right KIR00301 KIR00311 KIR00312
Right
materials and ingredients. KIR02100* (Lightweight) – KIR02111 –
Note: Kit is designed for use with a seat that properly
fits the driver. If seat is too large, two kits will be KIR00400 Left KIR00401 KIR00411 KIR00412
required. KIR02200* Left – KIR02211 –
(Lightweight)
Shoulder Supports
KIR00500 Right KIR00501 KIR00511 KIR00512
KIR00600 Left KIR00601 KIR00611 KIR00612
* Special lightweight supports are for use with 56LW and 58LW Series
seats only.
420
