Page 415 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

PRO SERIES III POWER STEERING
ALUMINUM POWER STEERING PUMPS FLOW CONTROL VALVES
The Pro Series III are among the most efficient power steering Aluminum Flow Control Valves are offered in several
pumps currently available. Pulley-driven, 9.6cc aluminum- different flow rates, making it possible to custom tailor steering
bodied pumps feature three different pressure relief valve “feel” on all KRC power steering pumps. Flow control valves may be used in
options, 1,200 PSI, 1,450 PSI and 1,600 PSI to accom- 9.6cc Pro Series Aluminum or 13.5cc cast iron pumps.
modate race cars with high-geared steering systems 9.6cc Alum. Pump 13.5cc Iron Pump
that operate at lower pressures. Pulley and mounting Part No. Description Flow (GPM) Flow (GPM) Identification
bracket kit must be purchased separately. KRC25304000 -6AN Male 1.18 1.66 4
Part No. Description KRC25306000 -6AN Male 1.70 2.35 6
KRC29116811 Pro Series III Pump, 9.6cc KRC25307000 -6AN Male 1.96 2.67 7
KRC29116813 Pro Series III Pump With Bolt-On Tank, 9.6cc KRC25308000 -6AN Male 2.22 2.91 None
Related Components KRC25309000 -6AN Male 2.41 3.32 B
KRC20011000 6.0" V-Belt Pulley, All KRC Aluminum Pumps KRC25310000 -6AN Male 2.65 3.75 C
KRC20015000 4.2" 6-Rib Serpentine Pulley, All KRC Aluminum Pumps KRC25311000 -6AN Male 2.75 4.01 D
KRC20017600 6.0" 6-Rib Serpentine Pulley, All KRC Aluminum Pumps KRC25312000 -6AN Male 2.92 4.21 E
KRC82308032 32-Tooth/30mm Wide HTD Pulley, All KRC Aluminum Pumps
KRC82308040 40-Tooth/30mm Wide HTD Pulley, All KRC Aluminum Pumps POWER STEERING
KRC89008040 Rock Guard With Screws For 40-Tooth HTD Pulley FLOW CONTROL
VALVE PACKAGE
SHAFT DRIVE/PTO PRO SERIES III KRC25300912
ALUMINUM POWER STEERING PUMP KRC offers a flow control package that provides more
Designed to be used in conjunction with a dry sump oil assist and less feel, while achieving maximum steering
pump, PTO Pro Series III 9.6cc aluminum pumps are avail- control. Package includes four flow control valves.
able with 3/8" hex drive or 17-spline. Requires pulley and
pump adapter for mounting.
Part No. Description
KRC29116821 Shaft Drive/PTO Pump, 17-Spline
Shaft Drive/PTO Pump,
KRC29316811
3/8" Hex Drive POWER STEERING
Shaft Drive/PTO Pump, PUMP BRACKET KITS
KRC29316821 3/8" Hex Drive, 3/8" Female Hex Aluminum brackets have longer adjustment slots
On Rear For Fuel Pump and captive nut for simple installation. Dual bolt
pattern mounts GM or KRC style pumps. Choose
CAST IRON from complete kits or mounting bracket only.
POWER STEERING PUMPS Kit Bracket Only
Pumps can deliver 1.5-3.7 GPM depending upon which flow valve Description Part No. Part No.
Chevy Head Mount,
is used. Directly replaces Saginaw pump and shares the same Mounts Pump to Left Cylinder Head KRC31410000 KRC31411000
pulley offset and mounting pattern. Complete kits, Chevy Block Mount,
which include pump, reservoir and V-belt or Mounts Pump Left Of Timing Cover KRC31415000 –
serpentine pulley, are also available for small Ford Head Mount,
block Chevy in cylinder head mount or block Mounts Pump to Left Cylinder Head – KRC31611000*
mount versions. * Bracket is designed for use with KRC31613000 Spacer Kit
Part No. Description KRC50000100
Power Steering Pumps
KRC50000100 Power Steering Pump With Bolt-On Tank
KRC50010000 Power Steering Pump, 6" V-Belt Pulley
KRC50010100 Power Steering Pump, 6" V-Belt Pulley And Bolt-On Tank
Power Steering Pump
KRC50020100
With Bolt-On Tank And 4.2” 3-Rib Serpentine Pulley
Power Steering Pump Kits
(Includes Pump, Reservoir And Mounting Bracket)
KRC59010010 Power Steering Pump Kit, Head Mount, 6" V-Belt Pulley
KRC59010015 Power Steering Pump Kit, Block Mount, 6" V-Belt Pulley
Accessory Components
Aluminum 6.0” 6-Rib Serpentine Pulley,
KRC50217600
For Cast Iron P/S Pump
Aluminum 6.5” 6-Rib Serpentine Pulley,
KRC50219650*
For Cast Iron P/S Pump
* Pulley is specially offset for GM F-Body/LS engine applications.
