Page 428 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

LIGHTWEIGHT 16-VOLT
RACING BATTERIES RACING BATTERIES
Lightweight, maintenance-free Valve Regulated Sealed, Absorbed Glass Mat (AGM) batteries
Sealed Lead Acid Battery (VRSLAB) was originally are powerful enough for modern racing
developed for military aircraft where weight, power ignitions and starting requirements. Batteries
and safety are priorities. This also makes it the perfect never need water and charge more quickly than
choice for today’s racer. May be mounted in any conventional batteries. Available in two- and
position and will not leak, even if the case is damaged. three-post versions. Three-post battery can ac-
Battery mounts are also offered. commodate 12-volt gauges, lights, etc. with the 12-volt
Reserve Peak Battery terminal and ignition, and starting circuits with the 16-volt
Part No. CCA Capacity Dis. Amps Dimensions Mount Weight terminal.
1400 @ 5.25" L. x 4.50" W.
REAAP1228 550 28 Mins. – 18 lbs. Reserve
20 Sec. x 7.0" H. Part No. Description Capacity CCA Dimensions Weight
1200 @ 7.625" L. x 5.25" 16-Volt 10.23" L. x 6.60" W.
REAAP1236 775 36 Mins. REA2010 24 lbs. REA1640TB 85 mins. 1050 42 lbs.
15 Sec. W. x 6.875" H. Battery, 2 Post x 8.31" H.
REAAP1257 850 57 Mins. 1500 @ 9.75" L. x 5.25" W. – 31 lbs. REA16/1240TB 16-Volt 85 mins. 1050 10.23" L. x 6.60" W. 42 lbs.
10 Sec. x 6.875" H. Battery, 3-Post x 8.31" H.

LITHIUM POWERPACK 16-VOLT BATTERY
AND BATTERY CHARGER COMBOS
The cost effective method of switching to lithium-ion
LITHIUM POWERPACK batteries. Each combo includes a Lithium Powerpack
12-VOLT BATTERY 16-volt battery and Intellich-
Exceptionally lightweight, 12-volt Lithium Power-pack battery features world arger battery charger. Fully
class lithium-ion performance at an affordable price. “C” series battery is automatic charger produces
designed to be alternator compatible. Battery includes fast cell balancing for 15 amps @ 18.4 volts, and
safety, long life and maximum capacity. Requires 12-volt Intellicharger. includes LED status indicators
Max for voltage, charge amperage,
Part No. Description Dimensions Weight Amps AH state-of-charge, amp-hours charged
LPBC680 C680 12V 7.16" L. x 3.30" W. x 6.57" H. 4.63 lbs. 800 11 and time of on-charge. The “L” series
batteries include low voltage MOSFET protection. Batteries may be purchased
LITHIUM POWERPACK 16-VOLT BATTERY separately, but must be charged using a lithium-ion specific 16-volt battery
LPBT1600 charger; see note below.
Popular with late models or modifieds, 16-volt
Max
Lithium Ion racing battery features plenty of reserve Combo Kit Battery Only Description Dimensions Wt./ Amps AH
Part No.
Lbs.
Part No.
capacity for events of 100 laps or more. Powerpack 6.25" L. x 6.93" W. x
battery has the same dimensions as a Group 34 unit, LPBL925-16ACK LPBL925-16A L925 16V 4.92" H. 6.12 880 11
yet packs incredible power, while weighing just 10.5 10.28" L. x 6.75" W. x
lbs. Requires Lithium Intellicharger 16-Volt battery charger. LPBL1600ACK – L1600 16V 7.24" H. 11.87 1200 23
Max Note: A charger for a 16v lead acid battery is not compatible with a 16v
Part No. Description Dimensions Weight Amps AH lithium battery. The set points and charging methods are different. A 16
16-Volt volt lead acid charger will certainly damage a 16 volt lithium battery
LPBT1600 10.24" L. x 6.93" W. x 7.2" H. 10.5 lbs. 1600 20
Battery regardless who the manufacturer is.
LITHIUM INTELLICHARGER
BATTERY CHARGERS
Designed specifically for charging lithium-ion bat-
teries, Intellicharger is offered in 12- and 16-volt
versions; the 12-volt charger produces 14
amps @ 14.4 volts, while the 16-volt unit
provides 15 amps @ 18.4 volts. Fully automatic
chargers include LCD status indicators for voltage,
amperage, state-of-charge, amp-hours charged and
time of on-charge.
Part No. Description
LPB1008 Lithium 16-Volt Intellicharger
LPB1011 Lithium 12-Volt Intellicharger
