ALUMINUM TURN PLATES QUICKSET LW ADAPTER LON78430
LON79800 The quickest way to check front end alignment on cars fitted with
Check Ackermann and other steering related wheels up to 22”. Simply place against a front wheel rim for quick,
settings with outstanding accuracy. Lightweight accurate readings using your existing caster camber gauge. Preci-
design reads to 1/2° and is free floating in two sion, CNC-machined billet aluminum tool features a three-point
directions for no bind. Can be zeroed with the design that folds up for easy storage.
car in place. Sold per pair. Use with LON79750
spacers.
TOE-IN BAR LON79622
One person can perform toe
CASTER/CAMBER GAUGE measurements more quickly
Assures accurate front end set-ups without having to use and easily. Similar to Longacre
turn plates. Gauge measures camber to ±6° and caster #79620, but this new model requires
to +12° to -4°. Gauge is accurate to within 1/4°. Includes no scribe line and measures to the outside of the tire.
foam-lined carrying case. Spindle adapters may be purchased Slide the rod against the tire and measure toe to within 1/16".
separately. Toe-in bar is constructed from billet aluminum and features small wheels,
Part No. Description allowing it to easily slide underneath the car. Suitable for use on wide track
LON78250 Gauge and Case Only - No Adapter cars including Corvettes, etc.
LON78260 Gauge, Case and Magnetic Adapter
Adapters For Caster/Camber Gauge TOE-IN GAUGE
LON78405 Wide 5 Spindle, Howe 5 x 5, 1-13/16" LON79620
LON78410 Factory GM, 3/4"-20 When used with the LON79610 Tire Scribe
LON78414 Ford Pinto, 3/4"-16 Thread (available separately) one person can accurately set toe-in.
LON78422 Replacement Magnetic Adapter

DIGITAL CASTER/ BILLET ALUMINUM TIRE SCRIBE
CAMBER GAUGE LON79610
Designed for use with LON79620 Toe-In Gauge, Tire
LON78290 Scribe makes a true running line on the face of the tire.
Accurate Digital Caster Camber Gauge Rigid, billet aluminum scribe is spring loaded for
reads up to 1/10°, yet is affordable for easy, one person use.
any serious race team. The incorporated
AccuLevel may also be removed and
used as a separate angle finder. Sold with Super Magnetic Adapter and a metal TIRE TAPE LON50870
carrying case. Tape is 1/4" wide x 10' long.

BILLET CASTER/CAMBER GAUGE
LON78273 TOE-IN PLATES
Precision CNC-machined from billet LON79501
aluminum and laser engraved, Caster/Cam-
ber gauge features an expanded range. Unit Rest plates against the tire on
measures camber to + or -9° and caster +12° each side and use a tape measure.
to -4°. Glow-in-the-dark vials allow easy Two tape measures included.
reading and the CNC-machined, dead flat
surface offers exceptional accuracy. Magnetic
adapter must be purchased separately. DELUXE HD TOE-IN PLATES
LON79505
Thick, heavy duty toe plates provide increased
accuracy, and include a higher kick-out on bot-
tom, which holds the plate against the wheel
better. Magnets on one plate holds measur-
QUICKSET DIGITAL CASTER/CAMBER ing tapes in place and an incorporated pointer
GAUGE FOR LARGE WHEELS allows obtaining easy, accurate measurements.
LON78298 Sold per pair.
Engineered for road race applications fitted with 17"
to 22" cast aluminum wheels, new model QuickSet MINI CHASSIS HEIGHT CHECKER
Caster/Camber gauge for large wheels includes special “feet”
that adapt to wheel bead and center the gauge. Digital Acculevel LON78318
gauge reads to .1. Unit folds up for easy storage. Sold complete with A shortened, simplified version, Mini unit checks chassis
a foam-lined silver storage case. height quickly and accurately. Simply push unit under
car, raise the tape with the knob, pull it out and
read the height. Unit is accurate to 1/16" and
has a range of 2"-8".
Note: Unit does not measure height dynamically as you work, or if car is
on scales. It must be removed to read chassis height.
