Page 478 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

®
ULTRA 40 RACE BLUE MAX SPIRAL CORE
SPARK PLUG WIRE SETS COIL WIRE KIT MOR73235
One of the most powerful, RFI/EMI-proof Coil wires should be replaced regularly. Kit
spark plug wire sets available, with just 40 includes 3' Blue Max spiral core 8mm suppression
ohms of resistance per foot. Kevlar core is wire, wire stripping tool and 13-piece boot and
four times stronger than conventional Ara- terminal kit.
mid fiber cores. Available in universal or
custom sets. Custom fit wire sets in- BLUE MAX SOLID CORE
®
clude Ultra 40 insulated wire sleeve. SPARK PLUG WIRE SET
Choose from blue or black wire sets.
Blue Wire Set Black Wire Set Stainless steel, solid core 8mm wires
Description Part No. Part No. work with magnetos and other systems
Universal Wire Sets* that do not require (EMI) suppression wires.
90° Universal Wire Set MOR73800 MOR73814 Universal fit, with only spark plug end installed.
Straight Universal Wire Set MOR73801 MOR73815 Sets include distributor boots (HEI and Non-HEI) and 36" coil wire.
135° Universal Wire Set MOR73802 MOR73816 Part No. Description
Custom Fit Wire Sets MOR72800 SB Chevy With Straight Ends
SBC, 90° Plug, HEI, Front Of Motor Routing MOR27001 – MOR72820 SB Chevy With 90° Ends
SBC Over Valve Covers, 90° Plug, Non-HEI MOR73600 – Note: Universal wire sets do not include wire sleeve.
SBC Over Valve Covers, 90° Plug, HEI MOR73602 MOR73817
SBC Under Headers, 90° Plug, Non-HEI MOR73605 –
SBC Under Headers, 90° Plug, HEI MOR73607 MOR73818 INSULATED WIRE SLEEVE
Ford 351W, 135° Plug, HEI MOR73626 MOR73822 Extend spark plug wire life and insulate against exhaust header heat. For
* Universal wire sets do not include wire sleeve. best results, the sleeve should cover the entire wire from plug boot to distribu-
tor boot and then be sealed with MOR72030 or MOR72031 Shrink Sleeve.
ULTRA 40 COIL WIRE KITS Packaged in 25' lengths.
Part No.
Description
Coil Wire Kits allow installation of an ignition MOR72000 7-8mm, Blue
coil in a remote location or used for replacement MOR72002 7-8mm, Red
purposes. Available with or without sleeving, MOR72011 Ultra 40, Blue
which adds extra dielectric strength. Each kit
includes coil wire, coil boots, spark plug boots, SHRINK SLEEVE
distributor boots and necessary terminals. Completely seal spark plug and distributor boots and spark plug wire sleeve.
Part No. Description
MOR73238 Ultra 40 Coil Wire Kit, Unsleeved, Black, 72" Packaged 18 sleeves per set.
MOR73240 Ultra 40 Coil Wire Kit, Sleeved, Blue, 48" Part No. Description
MOR73241 Ultra 40 Coil Wire Kit, Sleeved, Black, 48" MOR72030 Blue
MOR72031 Black

BLUE MAX SPIRAL CORE NUMBERED SHRINK SLEEVES MOR72020
®
SPARK PLUG WIRE SETS Sleeves simplify spark plug wire
Independent testing confirmed that Blue Max spark plug wire sets have more identification and installation.
spark energy, better EMI suppression and higher dielectric strength than any Numbered from 1 through 8, sets
other wires. Spiral core wire sets are compatible with modern on-board elec- include two of each number to
tronics. Available in universal and custom fit sets with wire sleeving. Distributor identify both ends of the spark plug wires.
end of universal sets must be cut to proper length and have the boots and
terminals installed. HIGH TEMP SPARK PLUG BOOT SLEEVES
Non-flammable sleeves provide protection up to 1,200°F. Sleeves are 1" I.D. x
5-3/4" long and sold in two-packs.
Part No. Description
MOR71992 Blue
MOR71993 Red
MOR71994 Black
Custom Fit Wire Set MOR71995 Natural
Universal Wire Set
Part No. Description
Universal Wire Sets (HEI/Non HEI) SPARK PLUG WIRE SEPARATOR KITS
MOR73225 Blue, 90° Spark Plug Boots/Terminals Separators ac com mo date 7 to 9mm wires, with or without sleeves. Plastic
MOR73217 Yellow, 90° Spark Plug Boots/Terminals
MOR73219 Red, 90° Spark Plug Boots/Terminals sep a ra tors prevent crossfiring and can be used over valve cov ers or under
MOR73231 Black, 90° Spark Plug Boots/Terminals headers. Easily snap into place to hold wires securely. Packaged six to a card
MOR73226 Blue, Straight Spark Plug Boots/Terminals (2 each of 2, 3, and 4-hole separators).
MOR73218 Red, Straight Spark Plug Boots/Terminals Part No. Description
MOR73232 Black, Straight Spark Plug Boots/Terminals MOR72160 Blue
MOR73220 Blue, 135° Spark Plug Boots/Terminals MOR72161 Red
MOR73233 Black, 135° Spark Plug Boots/Terminals MOR72162 Yellow
Custom Fit Wire Sets MOR72163 Black
MOR72402 SB Chevy With HEI, Over Valve Cover, 90° Plug Terminals
MOR72405 SB Chevy, Under Header, Non-HEI, 90° Plug Terminals
MOR72407 SB Chevy, Under Header, HEI, 90° Plug Terminals

477
