QUICK FASTENERS FASTENER SPRINGS
Quick Fasteners join body panels, doors, front Use with both the flat and oval head fasteners. Refer to chart for proper
ends, fiberglass-to-metal, metal-to-metal, etc. application. Pack aged 10 to a card.
Steel or aluminum fasteners are offered in several lengths and head styles. Spring Spring .400" .450" .500" .550" .650"
Use with MOR71400, 71410, 71420, 71425 or 71430 fastener spring. Ten per Part No. Height Body Body Body Body Body
package. 1" Springs – Total Material Thickness Range
Part No. Description MOR71425 .250" .165"-.200" .215"-.250" .265"-.300" .315"-.350" .365"-.400"
Steel MOR71430 .325" .098"-.133" .148"-.183" .198"-.233" .248"-.283" .348"-.383"
MOR71272 Butterfly Head Fastener, 7/16" x .550" Long Body 1-3/8" Springs – Total Material Thickness Range
MOR71274* Oval Head Fastener, 7/16" x .400" Short Body MOR71420 .325" .105"-.148" .155"-.198" .205"-.248" .255"-.298" .355"-.398"
MOR71275* Oval Head Fastener, 7/16" x .450" Short Body MOR71410 .375" .055"-.098" .105"-.148" .155"-.198" .205"-.248" .305"-.348"
MOR71290 Flush Head Fastener, .450" Short Body MOR71400 .425" .005"-.048" .055"-.098" .105"-.148" .155"-.198" .255"-.298"
MOR71300 Flush Head Fastener, .500" Medium Body Note: To select the proper fastener/spring, determine the total thickness
MOR71310 Flush Head Fastener, .550" Long Body of the panels being joined including the space in between, if any. Select
MOR71350 Oval Head Fastener, .500" Medium Body the appropriate body length and spring height combination to provide the
MOR71360 Oval Head Fastener, .550" Long Body desired thickness range.
Aluminum
MOR71295 Flush Head Fastener, 5/16" x .400" Short Body QUICK FASTENER
MOR71296 Flush Head Fastener, 5/16" x .450" Short Body
MOR71297 Flush Head Fastener, 5/16" x .500" Medium Body REINFORCEMENT PLATES
MOR71298 Flush Head Fastener, 5/16" x .550" Long Body Plates provide a secure metal backing to prevent fastener
* Signifies quick fasteners with a 3/16" hex drive head. body rivets from pulling out of fiberglass body components MOR71495
and fastener spring brackets from cutting into body panels.
LARGE HEAD SELF-EJECT ING FAS TEN ERS Sold ten per package in standard and large sizes.
In de mand by racing’s finest chassis build ers, fasteners Part No. Description
are used on steel, alu mi num, fi ber glass body and MOR71490 Quick Fastener Reinforced Plates MOR71490
in te ri or pan els. Load force is more evenly distributed for MOR71495 Large Dia. Quick Fastener Reinforced Plates
less pull-through. Ten per package. Use Fastener Springs
MOR71400, 71410, 71420, 71425 or 71430. QUICK FASTENER WASHERS
Part No. Description MOR71370 MOR71610
MOR71370 .500" x 7/16" Body PTFE washers fit all quick fasteners,
MOR71375 .550" x 7/16" Body prevent paint damage. 25 per pack.
MOR71380 .500" x 7/16" Body, 3/16" Hex Drive
SELF-EJECTING FAS TEN ERS QUICK FASTENER WRENCHES
Spring-loaded but tons release quickly. Spring also Stainless steel wrench fits slot head, 1/4-turn fas ten ers far better than a
holds the but ton cap tive, a practical ne ces si ty for screw driv er, reducing the pos si bil i ty of dam aged fas ten ers and body pan els.
quick pit work sit u a tions. Use MOR71430 as a re place ment Non-slip, plas tic hand grip.
spring. Ten per card. Springs in clud ed. Part No. Description
Part No. Description MOR71600 Wide Head
MOR71440 0.400" x 5/16" Body, .098" To .133" Grip Range MOR71606 Heavy Duty
MOR71450 0.450" x 5/16" Body, .148" To .183" Grip Range Screwdriver Type MOR71600
MOR71500 0.500" x 5/16" Body, .198" To .233" Grip Range
MOR71530 0.650" x 5/16" Body, .348" To .383" Grip Range HOOD PIN SETS
Choice of lightweight aluminum or chrome plated steel hood pins. Each set
BUTTERFLY includes two 3/8" diameter hood pins and installation hardware. Steel hood pin
SELF-EJECT ING FASTENERS kits include a pair of vinyl-coated stainless steel lanyards, while special, quick
“Butterfly” grip on head sets these Fasteners apart from release use a self-contained design. Moroso recommends using six pins per
others and makes fastening and unfastening quick and hood.
easy. Use MOR71430 as a re place ment spring. Pack aged ten to Part No. Description
a card. Springs included. MOR39000 Aluminum Hood Pin Set
Part No. Description MOR39010 Quick Release Hood Pin Set
MOR71510 0.500" x 5/16" Body, .198" To .233" Grip Range MOR39015 Steel Hood Pin Set, 3" Long
MOR71540 0.650" x 5/16" Body .348" To .383" Grip Range MOR39016 Steel Hood Pin Set, 4" Long
QUICK FASTENER MOUNTING BRACK ETS
Brack ets can be fastened to any mem ber of the car to pro vide a convenient QUICK-RELEASE PINS
mount for quick fastener springs.
The ultimate in quick-release fas ten ing.
T-handle equipped pins are available in popular
sizes. Packaged two per card.
Part No. Description Part No. Description
MOR90380 1/4" Dia. x 1" Long MOR90404 5/16" Dia. x 3" Long
MOR71550 MOR71551 MOR71552 MOR71555 MOR90390 1/4" Dia. x 1-1/2" Long MOR90410 3/8" Dia. x 1" Long
Part No. Description MOR90395 1/4" Dia. x 2" Long MOR90420 3/8" Dia. x 2" Long
MOR71550 Use With MOR71425 Or MOR71430 Springs, 10-Pk. Steel MOR90400 5/16" Dia. x 1" Long MOR90430 3/8" Dia. x 3" Long
MOR71551 Flat, 10-Pk. Steel MOR90401 5/16" Dia. x 1-1/2" Long MOR90440 1/2" Dia. x 2-1/2" Long
MOR71552 90° Angle, 10-Pk. Steel MOR90402 5/16" Dia. x 2" Long
MOR71553 Lightweight 45°, Accepts 1" Springs, 10-Pk.
MOR71555 Hood, Panel Or Accessory Mount, 2-Pk. Steel
MOR71556 Same As MOR71555 Except Aluminum, 2-Pk.
