Page 543 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

ALUMINUM THREADED BODY SHOCKS STEEL REPLACEABLE BEARING SHOCKS
62 SERIES 55 SERIES
The 62 Series shock bodies are made of 6061 T-6 aluminum for Twin tube dampers have 2" O.D., chrome bodies, 9/16" hard chrome
strength and longevity. Use with QA1CK6201 coil-over kit. piston rod, 1-3/8" pistons and replaceable, 1/2" I.D. PTFE/Kevlar injec-
Valving Comp. Extended tion molded bearings.
Part No. Comp./Rebound Length Length Valving Extended
7" Stroke Shock Absorbers Part No. Comp./Rebound Comp. Length Length
QA16273 3 13.00" 20.00" 7" Stroke Shock Absorbers
QA16273-5 3-5 13.00" 20.00" QA15573 3 12.53" 19.53"
QA16274 4 13.00" 20.00" QA15575-3 5-3 12.53" 19.53"
QA16275 5 13.00" 20.00" QA15576 6 12.53" 19.53"
QA16275-3 5-3 13.00" 20.00" QA15576-4 6-4 12.53" 19.53"
QA16276 6 13.00" 20.00" QA15579-1 9-1 12.53" 19.53"
9" Stroke Shock Absorbers
QA16293 3 15.00" 24.00"
QA16293-5 3-5 15.00" 24.00"
QA16294 4 15.00" 24.00" STEEL REPLACEABLE BEARING SHOCKS
QA16295 5 15.00" 24.00"
QA16296 6 15.00" 24.00" 51 SERIES
Twin tube, 51 series shocks now incorporate an in-house machined body with
a 2mm larger inside diameter to allow easier gas bag installation. Deflective
disc valving provides increased sensitivity in valving response, control and
consistency. May be run upside down.
ALUMINUM Valving Comp. Ext.
THREADED SMALL BODY SHOCKS QA15173 Comp./Reb. 13.00" 20.00"
Length
Part No.
Length
3
82 SERIES QA15173-5 3-5 13.00" 20.00"
Aluminum body, 82 Series Shocks are up to 40% lighter than full size QA15174 4 13.00" 20.00"
shocks. Deflective disc valving offers increased sensitivity in response, QA15174-6 4-6 13.00" 20.00"
control and consistency. Shocks are fully rebuildable, revalvable and QA15174-10 4-10 13.00" 20.00"
5
QA15175
repairable. QA15175-3 5-3 13.00" 20.00"
20.00"
13.00"
Valving Comp. Extended QA15175-13 5-13 13.00" 20.00"
Part No. Comp./Rebound Length Length QA15176 6 13.00" 20.00"
5" Stroke Shock Absorbers QA15176-2 6-2 13.00" 20.00"
QA18253 3 10.38" 15.75" QA15176-4 6-4 13.00" 20.00"
6" Stroke Shock Absorbers QA15179-1 9-1 13.00" 20.00"
QA18262 2 11.38" 17.75" QA15193 3 15.00" 24.00"
QA18262-4 2-4 11.38" 17.75" QA15193-2 3-2 15.00" 24.00"
24.00"
QA15193-5
15.00"
3-5
QA18263 3 11.38" 17.75" QA15194 4 15.00" 24.00"
7" Stroke Shock Absorbers QA15195 5 15.00" 24.00"
QA18273 3 12.38" 19.75" QA15195-3 5-3 15.00" 24.00"
6
QA15196
QA18274 4 12.38" 19.75" QA15196-2 6-2 15.00" 24.00"
15.00"
24.00"
QA18275 5 12.38" 19.75" QA15197-2 7-2 15.00" 24.00"
Note: Shocks are also available in 8" and 9" strokes. QA15197-4 7-4 15.00" 24.00"
QA15198-2 8-2 15.00" 24.00"
QA15199-2 9-2 15.00" 24.00"
STEEL SMALL BODY SHOCKS STEEL MONOTUBE
STOCK MOUNT SHOCKS
70 SERIES 27A SERIES IMCA-LEGAL
Twin-tube, 1-5/8" O.D. shock bodies house aluminum pistons and
base valves, 1/2" centerless ground, hard chrome piston rods and Similar to the 27 series, but the gas pressure tunability has been dis-
replaceable, 1/2" I.D. bearings. Shocks may be rebuilt and re-valved, abled to meet IMCA rules. Stock mount, IMCA-legal shock absorbers
and can be run upside down to reduce unsprung weight with no include a damping curve that allows for complete suspension control
change in rate. at low shaft speeds without creating extreme forces at high shaft
Comp. Extended velocities. Racer rebuildable and revalvable, electroless nickel plated
Part No. Valving Comp./Rebound Length Length body shocks are made in the USA, 100% dyno tested and serialized.
7" Stroke Shock Absorbers Valving Comp. Extended
Length
Length
Application
Part No.
QA17073 3 12.39" 19.77" QA127A683-5M GM Metric Rear Comp./Rebound 13.35" 21.81"
3-5
QA17074 4 12.39" 19.77" QA127A684M GM Metric Rear 4 13.35" 21.81"
QA17075 5 12.39" 19.77" QA127A685M GM Metric Rear 5 13.35" 21.81"
QA17075-3 5-3 12.39" 19.77" QA127A688-2M GM Metric Rear 8-2 13.35" 21.81"
QA127A943-5M GM Metric Front 3-5 9.17" 14.00"
QA127A943-8M GM Metric Front 3-8 9.17" 14.00"
QA127A945-3M GM Metric Front 5-3 9.17" 14.00"
QA127A945M GM Metric Front 5 9.17" 14.00"
