Page 548 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

LOW GROUND CLEARANCE CLUTCHLESS
BELLHOUSING KITS BELLHOUSING KITS
Low Ground Clearance (LGC) kits use of a Ideal for dirt or asphalt late models with
small diameter, 99-tooth ring gear and flat- clutchless transmissions, housings work with
bottom bellhousing that are flush with 1/4" midplates, top or side mount oil
the shallowest of dry sump pans, thereby pumps and Bert/Brinn standard
allowing the nose of the car to be as low rotation or Quarter Master reverse
to the track as possible, maximizing downforce. rotation starters. Available in mag-
Designed for circle track or road race applica- nesium or aluminum for early Chev-
tions using 5.5" diameter clutches. Complete rolet bolt pattern. (unless specified).
kits are sold with magnesium LGC bellhousing, Part No. Description
Optimum-V 3-disc clutch assembly, Tri-Lite Aluminum Bellhousing Kit
hydraulic release bearing, Ultra Duty starter and necessary hardware. Bellhousing, Top Mount Pump
Part No. Description QTR120509124TM Bracket, 91T Ring Gear, Rev. Rotation Starter
Chevy LGC Bellhousing Kit, Int. Balance, (Quarter Master Style)
QTRLGC150375091 Magnesium Bellhousing Kits
2-Pc. Rear Main
QTRLGC350375091 Ford LGC Bellhousing Kit, Neutral Balance QTR115509124TM Bellhousing, Top Mount Pump Bracket, 91T Ring Gear,
Rev. Rotation Starter (Quarter Master Style)
Replacement Components Replacement Components
QTR110089 LGC Ring Gear, 99-Tooth QTR110115 Magnesium Bellhousing Only, No Mounts
QTR114626 Ultra Duty Starter, 2.0 KW QTR110120 Aluminum Bellhousing Only, No Mounts
QTR114170 Bert Style Standard Rotation Starter
CHEVY V-DRIVE 5.5" QTR114176 Starter Plate For Quarter Master Starter
REVERSE MOUNT BELLHOUSING KITS QTR114177 Starter Conversion Plate, Adapts Bert/Brinn Starter
To Quarter Master Bellhousing
Triple disc, 5.5" V-Drive scalloped button clutch com- QTR114267B Starter 8T For 91T Ring Gear, New Style
bines reliability and low MOI (moment-of-inertia). QTR117600 Oil Pump Bracket Kit, Top Mount
Kits include aluminum reverse mount starter bell- QTR117603 Oil Pump Bracket Kit, KSE/KRC Pump
housing, 1-5/32" x 26-spline, clutch assembly QTR180121 Crank Hub, Pump Drive, 22T Steel
with button and ring gear, flywheel QTR180123 Drive Hub Assembly, No Pump Gear, Chevy
bolt kit, hydraulic release bearing, QTR180171 Balance Weight, Chevy, Late
reverse mount starter, clutch inlet QTR505004 Dirt Flywheel Bolt Kit, 1.260" Long
and bleed line kit. Available for QTR505012 Flywheel Bolts, Chevy Late
internally or externally balanced small QTR509124 Flywheel, 110T Bert, Chevy, Old Style, 2-pc. Rear Main
block Chevy. QTR509124B Flywheel, 91T Bert, Chevy, New Style, 2-pc. Rear Main
Part No. Description QTR509134 Chevy Flywheel, Pre-1986, LGC 110 T, 7.25" Bert/Brinn
Early, Pre-1986 Small Block Chevy QTR509134B Flywheel, 91T Bert/Brinn, Late Chevy 1-Pc. Rear Main
(Internal Balance) Bellhousing Kits QTR509139B Flywheel, 91T Bert/Brinn, With Coupler, Chevy
QTR10038590 5.5" Reverse Mount Assy., 3-Disc, 1-5/32" x 26-Spline
Late, 1986-Up Small Block Chevy
(External Balance) Bellhousing Kits LIGHT STEEL BELLHOUSING
QTR10038590ZZ 5.5" Reverse Mount Assy., 3-Disc, 1-5/32" x 26-Spline
Replacement/Related Components QTR110432
QTR105401 Pressure Plate Steel bellhousing, weighs just 19 lbs., accepts
QTR105406 Floater Plate up to 10-1/2" dia. clutches and is compatible with
QTR110018 Ring Gear, One-Piece stock or Quarter Master starter. Fits Chevy or Ford,
QTR1100182D 2-Disc Spacer clutch or clutchless transmissions. Use with Tri-
QTR1100183M Mid-Plate Spacer Lite or floating hydraulic bearing.
QTR110100R Aluminum Reverse Mount Bellhousing, Chevy Part No. Description
QTR205508 Button Clutch Bolt Kit, 2-Disc Related Components
QTR275018 Ring Gear For 5.5" 2-Disc Clutch QTR114371 Ford Starter Spacer, .460"
QTR305508 Button Clutch Bolt Kit, 3-Disc QTR114373 Ford Starter Spacer, .250"
QTR505170SC Button Internal Balance, Pro-Series, V-Drive, Pre-1986 Chevy V-8 153T Flexplate, Early,
QTR509121 Internal Balance
CHEVY DS REAR MOUNT STARTER QTR509171 Chevy V-8 153T Flexplate, Late, Internal Balance
BELLHOUSING KIT QTR10038591DS QTR509181 Late Chevy V-8 153T Flexplate, Ultra Light (2.9 lbs.)
Innovative new rear mount starter QTR509322 Ford V-8 157T Standard Flexplate, Internal Balance
bellhousing kit helps improve handling Note: Use of a stock Ford starter requires a QTR114371 starter adapter.
characteristics by locating the dry
sump oil pump low and on the left STEEL “BLOCK MOUNT STARTER”
side of the bellhousing, while also BELLHOUSING QTR110440
providing less oil line length and Chevy, race-proven steel bellhousing can accom-
bulk. Kit is complete with 5.5", modate a stock diameter flywheel and also offer
26-spline V-Drive clutch, oil clearance for use with a traditional, block mount
pump mount bracket, oil pump starter. Bellhousing is CNC-machined to ultra-tight
drive, Tri-Lite release bearing, tolerances and is designed for use with the Tri-Lite
bearing retainer and necessary hardware. Oil pump not included.
and FloatingHydraulic Race Bearing. May be used
with 5.5" or 7.25" diameter clutch assemblies.

547
