FUEL SYSTEM COMPONENTS

STEEL CARB LINKAGE
26" steel linkage kits with quick disconnects speed up carb changes and
servicing. ALL54170 includes one 1/4"-28 LH rod end and one quick discon-
nect. ALL54171 includes two quick disconnects. ADJUSTABLE GAS PEDALS
Fully adjustable aluminum gas pedals are available for
straight or angled foot box panels. Bronze bush-
ings and nylon rollers provide smooth operation.
Linkage arm has 1/4" holes spaced every 1/2"
for adjustment of throttle linkage.
Part No. Description
ALL54170
ALL54098 Straight ALL54099
ALL54099 Angled

ALL54171
Part No. Description
One Quick Disconnect
ALL54170
And One 1/4"-28LH Rod End
ALL54171 Two Quick Disconnects HEEL RISER
Replacement Components Aluminum heel risers are drilled for easy
ALL54172 Throttle Ball mounting and include a non-skid pad.
ALL54173 RH Quick Disconnect 4-1/2" wide.
ALL54174 LH Quick Disconnect Part No. Description
ALL54175 24" Throttle Rod ALL54090 1" Tall Riser
ALL54091 1-1/2" Tall Riser
ADJUSTABLE IDLE KIT
ALL54154
Need cold start help to keep your race car THROTTLE PEDAL
running and get it warmed up? This ASSEMBLY ALL54106
kit allows you to adjust your idle Rugged aluminum pedal may be mounted
speed from inside the cockpit! All to the floor pan or lower frame rail for
items mount inside the foot box to smooth, safe throttle control. Includes
stay clean and away from the carb it- return spring bracket and fasteners.
self! Designed to work with throttle ped-
als that have a flat surface on the arm, like
Allstar ALL54098, bracket bolts to the foot
box and adjusts against the top arm of the throttle pedal.
Once your car is started, simply turn the adjustment knob to the desired idle
setting. Kit is complete with adjustment knob, 5 ft. cable assembly, mounting
bracket and hardware. Throttle pedal sold separately. THROTTLE/SHIFT CABLES
Cables have many uses including use as a
GAS PEDALS throttle cable or as a shifter cable in many
Gas pedals can be pulled back if throttle binds or return spring fails. Side applications. Cables have 7/16" mounting
mount pedals are available as standard or roller design for smoother throttle threads,
control. Firewall mount pedal is used on racecars with flat or stock type 10-32 RH cable ends and 3" of travel.
firewalls. Cables are listed as overall length.
ALL54100 Part No. Description
ALL54142 43"
ALL54101 ALL54107 ALL54145 60"

FUEL CELL CAP AND BOLT-IN BUNG KITS
Billet aluminum neck looks good and provides a positive seal. The filler neck
is raised to help prevent dirt and debris from falling into cell causing fuel sys-
tem contamination while the large opening helps when refueling. Kit includes
mounting hardware.
Part No. Description
ALL40133 12-Bolt JAZ/RCI Style
ALL40134 6-Bolt JAZ Style
Part No. Description Replacement Part
ALL54100 Standard ALL40135 Replacement Cap ALL40134
ALL54101 Roller
ALL54107 Firewall Mount
