Page 77 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

HUBS, BEARINGS AND SEALS

SPINDLE NUT KITS FRONT HUB DUST CAPS
Spindle nut kits include all required hardware to Stock replacement style dust caps.
retain hub and rotor to spindle or axle tube. Part No. Description
2" PIN KIT (WIDE 5 AND 5X5 HUBS) ALL72164 GM Metric Hub, 2-3/32" O.D.
2" pin kit for Allstar, Howe, PCR 5x5 and most ALL72165 Ford Hub, 1-25/32" O.D.
Wide 5 hubs include a retaining nut, tabbed wash-
er and a tabbed locking ring with locking screws.
Retaining nut has 1-13/16"-16 RH threads. MASTER WHEEL
Part No. Description BEARING AND SEAL KITS
ALL44130 Steel Spindle Nut Kit Kits contain all components to install
ALL44131 Aluminum Spindle Nut Kit one brake rotor/hub assembly including
ALL10110 Spindle Nut Socket For ALL44130 And ALL44131 hub seal, inner bearing, outer bearing,
ALL44132 Locking Screws For ALL44130, 4-Pack locknut kit and dust cap.
ALL99172 Locking Screws For ALL44131, 4-Pack
Part No. Description
Intermediate Metric Hub Kit,
ALL72305
1979-81 ALL72305
Intermediate Metric Hub Kit,
ALL72306 1982-88
2.5" PIN KIT (5X5 HUBS) ALL72308 Granada/Mustang II Hub Kit
2.5" pin kit for Allstar, AFCO and Winters 5x5
hubs include a retaining nut, tabbed washer WHEEL BEARING KITS
and a tabbed locking ring with locking screws. Kits contain inner bearing, outer bearing and seal.
Retaining nut has 2-3/8"-18 RH threads.
Part No. Description
Part No. Description
ALL72173 Steel Spindle Nut Kit, RH ALL72300 Wide 5 Kit, Wilwood, Sierra,
ALL72174 Steel Spindle Nut Kit, LH Winters
ALL10115 Spindle Nut Socket For ALL72173 ALL72301 Wide 5 Kit, Howe (Contender
Hub Only)
ALL44132 Locking Screws For ALL72173, 4-Pack
ALL72302 5x5 Kit, 2.0" Pin
GM NUT KIT ALL72160 ALL72303 5x5 Kit, 2.5" Pin
Kit for 1978-88 Metric Chassis stock type
spindles includes a 3/4"-20 retaining nut, tabbed TIMKEN WIDE 5
washer and a cotter pin. WHEEL BEARING KIT
ALL72310
This wheel bearing and seal kit is designed
MUSTANG II KIT ALL72161 to fit most Wide 5 hubs. The complete kit will
update one hub and includes inner and outer
Kit for most Mustang II stock type spindles wheel bearings, inner and outer races and a low
includes a 13/16"-20 retaining nut, tabbed drag hub seal.
washer, crown washer and a cotter pin.

WHEEL BEARINGS
Description Inner Bearing Inner Race Outer Bearing Outer Race
Standard
Wide 5 ALL72215 ALL72230 ALL72245 ALL72255
5x5 2.0" Pin, Allstar, Howe, PCR ALL72200 ALL72260 ALL72200 ALL72260
5x5 2.5" Pin, GN, AFCO, Winters, SCP ALL72210 ALL72225 ALL72210 ALL72225
Ford Granada ALL72270 – ALL72274 –
GM Metric 1979-81 Monte Carlo, etc. ALL72275 – ALL72277 –
GM Metric 1982-88 Monte Carlo, etc. ALL72275 – ALL72278 –
Timken
Wide 5 ALL72217 – ALL72247 –
5x5 2.0" Pin, Allstar, Howe, PCR ALL72202 – ALL72202 –
5x5 2.5" Pin, GN, AFCO, Winters, SCP ALL72212 – ALL72212 –
Ford Granada ALL72280 – ALL72281 –
GM Metric 1979-81 Monte Carlo, etc. ALL72282 – ALL72284* –
GM Metric 1982-88 Monte Carlo, etc. ALL72282 – ALL72283 † –
REM Finished
All Wide 5 (Exc. Howe) ALL72216 ALL72231 ALL72246 ALL72256
* Bearing For Race Or Cup With A 1.97" O.D.
† Bearing For Race Or Cup With A 1.78" O.D.

76
