TOOLS AND PIT EQUIPMENT

Ball Joint Spreader Tool ALL11174 Safety Wire Drill Fixture ALL10122
Tool separates ball joint from the spindle. Inside of cyl- Accurately drill holes in fasteners allowing
LQGHU LV VKDSHG WR ¿W RYHU WDSHUHG VWXG RI PRVW EDOO MRLQWV them to be mechanically locked in
and presses against stud of other ball joint. Not for use on place with safety wire. Fixture ac-
FWD or 4WD applications. Tool is 4" tall fully collapsed commodates 3/16", 1/4", 5/16", 3/8",
and 6" tall fully extended. 7/16", 1/2" and 5/8" fasteners. Guide
Part No. Description bolt tightens against fastener, holding
Related Component it secure for drilling. Fixture includes
ALL11175 1" Extensions (Set of two) ALL11175 two guide bolts and two 1/16" drill bits conveniently stored within
WKH ¿[WXUH
Part No. Description
Taps Replacement Component
Tungsten steel taps are titanium coat- ALL99102 Replacement Drill Bits, 2-Pack
ed. Economy taps are available in
right-hand and left-hand threads. Dial Indicator With Magnetic Base
Part No. Description Part No. Description ALL96414
ALL11060 1/4"-20 RH ALL11065 1/2"-20 LH
ALL11061 1/4"-28 RH ALL11066 5/8"-18 RH Dial indicator with magnetic base is a necessity
ALL11062 3/8"-16 RH ALL11067 5/8"-18 LH when degreeing a camshaft, checking crank-
ALL11063 3/8"-24 RH ALL11068 3/4"-16 RH shaft end play, deck heights, dome heights,
ALL11064 1/2"-20 RH ALL11069 3/4"-16 LH transmission end play or ring and pinion back-
lash. Universal magnetic base may be mounted
NPT Taps anywhere. Shockproof dial indicator has 1" of
travel in .001" increments. Base and dial indicator
Alloy steel taps work well for chasing and cleaning threads may also be purchased separately.
EHIRUH LQVWDOOLQJ ¿WWLQJV DQG SOXJV
Part No. Description
Part No. Description ALL96415 Dial Indicator Only
ALL11056 1/8"-27, NPT ALL96416 Magnetic Base Only
ALL11057 1/4"-18, NPT
ALL11058 3/8"-18, NPT
ALL11059 1/2"-14, NPT Digital Calipers 0-6" With Case ALL96411
Measure inside, outside
Thread Files and depth dimensions with
easy to read Metric or SAE
Remove burrs from
damaged or rusted LCD display, in .001" incre-
ments up to 6". On/Off switch
external threads on bolts, spindles, axle tubes, threaded shaft, conserves battery and zero
SLSH DQG SLSH ¿WWLQJV &KRRVH IURP WKUHH GLIIHUHQW ¿OHV HDFK setting assures accurate readings.
8-1/2" long. Standard and metric sizes.
Plastic case provides additional battery
Part No. Description storage.
ALL11037 11-12, 13-14, 16-18, 20-24TPI
ALL11038 9-10, 12-16, 20-27, 28-32TPI
ALL11039 .80-1.00, 1.25-1.50, 1.75-2.00, 2.50-3.00mm Dial Caliper ALL96410
Quality hardened
stainless steel dial
caliper is shock-
Safety Wire proof and capable
Twister Pliers ALL10120 of measuring items
Never lose another race because from .001" to 6" in
of loose bolts. Rugged pliers have an increments of .001". Includes protec-
end bearing for smoother, faster twisting, tive carrying case.
especially in tight areas where a second pull
is needed.
Runout Checker
ALL96440
Fixture provides an
Safety Wire ALL10121 easy way to check
Stainless steel wire is .032" dia., for bent torque tubes,
1 lb. spool. drive shafts, torsion bars
or radius rods and measures
16-1/2" overall.
