Page 125 - 2019-2020 Racecar Engineering Circle Track Parts and Accessories Catalog

SUSPENSION

Leaf Spring Slider Box Leaf Spring Slider Box
ALL60034 ALL60035
Leaf spring slider box replaces Replace rear leaf spring shackles
conventional leaf spring shackles with Allstar’s leaf spring slider box.
to enable effortless suspension Bolt-in slider box with roller bear-
movement and prevent binding. ing design eliminates leaf spring
Box may be welded, or bolted directly binding, freeing up car. Fits 2-1/2"
to chassis and includes two nylon bushings wide Chrysler type leaf springs.
with spring mounting hardware. Fits 2-1/2" wide Chrysler type
leaf springs.
Part No. Description
Replacement Part
ALL99055 Bushings, 2-Pack

TOOLS AND PIT EQUIPMENT

Tubing Notchers Digital Level ALL10744
Notchers render precise joints for more consistent welds Digital level with powerful mag-
and stronger cages. Available in deluxe aluminum netic base measures the angle of a
or economy steel versions, notchers accept up to single straight surface or the angle
2" diameter stock and automatically align and center of a joint between two straight surfaces. Displayed value on the
tubing. Use in drill press or with hand drill. Notch- LCD screen rotates to right side up when level is in an upside
ers adjust up to 45°. down position. Powered by three 3V CR2032 batteries (includ-
Part No. Description ed). 6" x 2.25" x 1.25".
ALL10400 Deluxe Aluminum
ALL10411 Economy Steel
Replacement Parts Smart Tool ALL10113
ALL10402 5/8"-18 Thread Adapter Ensure that chassis tubing is level
ALL10403 Arbor Support Bushings (Pair)
ALL10404 Arbor With 1/2"-20 Thread and plumb when building roll cages
Optional Parts ALL10400 or checking driveshaft angles. Pow-
ALL10405 Arbor With 5/8"-18 Thread ered by a standard 9 volt battery.
ALL10406 Drill Press Mount (ALL10411 Only)
ALL10407 Arbor Support With Needle Bearings
Note: Tubing notchers include 1/2"-20 arbor thread and 5/8"-18 adapter. Smart Tool Tray ALL10740
Hole saws up to 1-1/8" diameter use 1/2"-20, larger hole saws use 5/8"-18 Aluminum tray is a nice addition
thread. when using Smart Tool on 7/8" and
1" O.D. trailing arms or suspension
tubes. Plastic clips allow tray to snap
Hole Saw Set ALL10412 to tube when in tight areas. A bubble level
Use with tubing notchers. Does not include an arbor for a hand helps provide accurate readings.
drill. Set includes one of each size: 3/4", 1", 1-1/8", 1-1/4", 1-1/2"
1-5/8" and 1-3/4".
Part No. Description Level Base ALL10741
Individual Hole Saws /HYHO EDVH VLPSOL¿HV QRWFKLQJ
ALL10413 3/4" and bending of round tubing
ALL10414 1" and helps ensure accuracy. Base
ALL10415 1-1/8" fastens to standard ballast or weight
ALL10416 1-1/4" brackets and clamps to the tube as a refer-
ALL10417 1-1/2"
ALL10418 1-5/8" ence point when creating parallel, perpendic-
ALL10419 1-3/4" ular, any angle of opposing notches or bends
Note: Hole saws up to 1-1/8" diameter use 1/2"-20 thread, larger hole saws during fabrication. Base accepts most digital
use 5/8"-18 thread. levels including ALL10113, ALL10742 and
ALL10744 or standard bubble levels. Digital scale and
Part No.
Description
Digital Level ALL10742 Individual Mounting Brackets mounting bracket
sold separately.
Digital level with magnetic base measures
the angle of a single straight surface or the ALL14192 1"
angle of a joint between two straight surfaces. ALL14193 1-1/4"
Displayed value on the LCD screen rotates to ALL14194 1-3/8"
right side up when digital level is in an upside ALL14195 1-1/2"
down position. Powered by three 3V CR2032 ALL14196 1-5/8"
batteries (included). 2" x 2" x 1". ALL14197 1-3/4" ALL14195

2019-20 CIRCLE TRACK PARTS AND ACCESSORIES 121
