Page 120 - 2019-2020 Racecar Engineering Circle Track Parts and Accessories Catalog

SUSPENSION

Threaded Tubing Ends 3/4" Solid Rod End ALL58112
Chrome moly 4130 steel tubing Solid rod ends are built using 1045 steel and are then
ends are ideal for building custom chrome plated for added wear resistance. Rod end has
length suspension tubes. Available in a body width of .875" to match the width of standard
RH and LH threads. rod ends.
Tube End Insert
Thread Size Tubing Size O.D. RH Part No. LH Part No.
10-32 3/8" x .058" .259" ALL22500 — 5/8" Rod End Reducer Spacers
5/16"-24 1/2" x .058" .384" ALL22504 —
3/8"-24 5/8" x. .058" .509" ALL22508 ALL22509 5HGXFHU VSDFHUV ¿W LQWR URG HQGV UHGXFLQJ WKH KROH VL]H
3/8"-24 3/4" x .058" .634" ALL22512 ALL22513 for 1/2" hardware while also spacing the rod end away from
1/2"-20 7/8" x .058" .759" ALL22518 ALL22519 FKDVVLV EUDFNHWV 6WDQGDUG VSDFHUV DUH 2 ' DQG ÀDQJHG
1/2"-20 1" x .058" .884" ALL22522 ALL22523 VSDFHUV KDYH 2 ' ÀDQJHV WR KHOS VXSSRUW URG HQG 6L]H UHIHU-
1/2"-20 1" x .065" .870" ALL22526 ALL22527 enced indicates the amount of space between rod end pivot ball
1/2"-20 1-1/8" x .058" 1.00" ALL22530 ALL22531 and chassis bracket. Package of 2.
5/8"-18 1" x .058" .884" ALL22534 ALL22535 Part No. Description
5/8"-18 1" x .095" .810" ALL22538 ALL22539 Standard Spacers
5/8"-18 1-1/4" x .095" 1.060" ALL22542 ALL22543*
5/8"-18 1-1/4" x .120" 1.010" ALL22546 ALL22547* ALL18615 Aluminum, 1/2"
3/4"-16 1-1/4" x .065" 1.120" ALL22548 ALL22549* ALL18617 Aluminum, 1"
3/4"-16 1-1/4" x .095" 1.060" ALL22550 ALL22551* Flanged Spacers ALL18615 ALL18612
3/4"-16 1-1/4" x .120" 1.010" ALL22554 ALL22555* ALL18611 Aluminum, 1/4"
3/4"-16 1-3/8" x .095" 1.185" ALL22558 ALL22559* ALL18613 Aluminum, 1/2"
* Tube end has built-in hex for adjusting.
ALL18610 Steel, 1/4"
ALL18612 Steel, 1/2"
Rod Ends
Two-piece spherical rod ends Jam Nuts - Standard Hex
have a pivoting steel ball and are Allstar Jam Nuts have many uses. Great for locking rod ends
sold each. tightly on suspension tubes or rack and pinion steering units.
Bore x Thread RH Male LH Male RH Female Strength 3DFNDJH RI XQOHVV VSHFL¿HG
Standard Series Steel Size Steel Part No. Alum. Part No.
1/4" x 1/4"-28 ALL58004 ALL58014 ALL58034 2,835 Lbs 1/4"-28 RH ALL18250 —
5/16" x 5/16"-24 ALL58005 ALL58015 ALL58035 4,517 Lbs 1/4"-28 LH ALL18251 —
3/8" x 3/8"-24 ALL58006 ALL58016 ALL58036 6,323 Lbs 5/16"-24 RH ALL18252 —
1/2" x 1/2"-20 ALL58008 ALL58018 ALL58038 10,046 Lbs 5/16"-24 LH ALL18253 —
5/8" x 5/8"-18 ALL58010 ALL58020 ALL58040 15,488 Lbs 3/8"-24 RH ALL18254 ALL18274
3/4" x 3/4"-16 ALL58012 ALL58022 ALL58042 15,894 Lbs 3/8"-24 LH ALL18255 ALL18275
3/4" x 3/4"-16 ALL58013 † — — 15,894 Lbs 7/16"-20 RH ALL18256 ALL18276
Pro Series Steel (Moly) – Black 7/16"-20 LH ALL18257 ALL18277
1/2" x 1/2"-20 ALL58058 ALL58068 — 17,000 Lbs 1/2"-20 RH ALL18258 ALL18278
1/2" x 5/8"-18 ALL58059 ALL58069 — 19,300 Lbs 1/2"-20 LH ALL18259 ALL18279
5/8" x 5/8"-18 ALL58060 ALL58070 — 18,000 Lbs 5/8"-18 RH ALL18260 ALL18280
3/4" x 3/4"-16 ALL58062 ALL58072 — 25,000 Lbs 5/8"-18 LH ALL18261 ALL18281
Pro Series Steel (Moly) – Black (PTFE Lined) 3/4"-16 RH ALL18262 ALL18282
1/2" x 5/8"-18 ALL58079 ALL58084 — 17,650 Lbs 3/4"-16 LH ALL18263 ALL18283
5/8" x 5/8"-18 ALL58080 ALL58085 — 15,200 Lbs 3/4"-10 RH ALL18264* † —
3/4" x 3/4"-16 ALL58082 ALL58086 — 21,400 Lbs 7/8"-9 RH ALL18266 (Sway Bar Adj. Nut) † —
Aluminum – Black 1"-8 RH ALL56110 (Jack Bolt Nut) † —
1/2" x 1/2"-20 ALL58088 ALL58098 — 7,700 Lbs * Commonly used with UBM35-1107, 3/4"-10 jack bolt.
1/2" x 5/8"-18 ALL58089 ALL58099 — 15,000 Lbs † Sold each
† ALL58013 has an oversized hole and is for use with steering shaft tubing.
Jam Nuts - Small Hex
Heavy Duty 3/4" Specialty jam nuts have smaller outside
Chrome Moly Rod Ends diameters allowing smaller wrenches to be
Heavy duty or often referred to as “Aircraft used when changing radius rod lengths. Example: with 1/2"
Style”, these 4130 chrome moly rod ends have bolts the same 3/4" wrench can be used to adjust radius rod or
larger bodies which make them thirty percent mounting hole locations. Package of 4.
stronger than standard 3/4" rod ends. These Steel Alum. Black Alum.
rod ends are commonly used on panhard bars Thread Size Wrench Size Part No. Part No. Part No.
and lower strut rods. 5/8"-18 RH 3/4" ALL18292 ALL18296 ALL18286
ALL99314 ALL99315 5/8"-18 LH 3/4" ALL18293 ALL18297 ALL18287
Part No. Description 3/4"-16 RH 15/16" ALL18294 ALL18298 ALL18288
ALL99314 RH Male, 3/4" x 3/4"-16 3/4"-16 LH 15/16" ALL18295 ALL18299 ALL18289
ALL99315 RH Female, 3/4" x 3/4"-16

116 2019-20 CIRCLE TRACK PARTS AND ACCESSORIES
