SUSPENSION

Quick Change Upper Link Spacer Kits
Upper Link Brackets ALL60154 Kits with multiple spacers allow the
Bracket attaches to top of quick change and top link to be positioned where ever
accepts upper link. Aluminum bracket is 1/4" needed between brackets. Spacers
thick, gold anodized and has a 3/4" x 4-1/2" have a .750" I.D. hole. Kits include
slot for quick adjustment. Sold in pairs. bolt, nut and spacers.
Part No. Description
ALL60148 Spacer Kit With Steel Spacers
ALL60158 Spacer Kit With Aluminum Spacers
ALL60152
1/4" thick aluminum bracket with 3/4" x 3" 90/10 Shock Brackets
slot bolts to top of quick change to accept ALL60026
upper link. Sold in pairs. Brackets weld to the chassis to mount a
shock between the chassis and the differen-
tial to control “unloading” during deceleration
RI KDUG EUDNLQJ WKLFN VWHHO EUDFNHWV ¿W
1-1/2" dia. tubing and have four 1/2" holes
ALL60150 spaced 1" apart. Sold in pairs.
Bracket attaches to top of quick change and
accepts upper link. Steel bracket has three 3/4" 90/10 Spacer Kits
holes, 3" to the rear for forward traction. Sold in Kits with multiple spacers allow
pairs. positioning of the 90/10 shock
where ever needed between
brackets. Spacers have a .500" I.D. hole.
Kits include bolt, nut and spacers.
Part No. Description
ALL60149 Spacer Kit With Steel Spacers
ALL60156 ALL60159 Spacer Kit With Aluminum Spacers
Bracket attaches to top of quick change
and accepts upper link. Steel bracket is Aluminum Suspension Tubes
1/4" thick with multiple holes, pop-
XODU RQ PRGL¿HGV 6ROG LQ SDLUV Clear anodized tubes have a machined
ZUHQFK ÀDW RQ RQH HQG IRU HDVH RI
adjustment. Tubes have .156"
wall thickness, are avail-
able in two diameters
Ford 9" Upper Link Brackets and a variety of lengths.
Ford 9" housing brackets provide a mounting The 56400 series tubes are 7/8" in diameter and both ends are
SRLQW IRU XSSHU OLQN :HOG RQ EUDFNHWV ¿W VWDQ- tapped 5/8", one RH and LH. The 56500 Series tubes are 1" in
dard steel Ford housings. diameter and both ends are tapped 3/4", one RH and one LH.
6061-T6 material.
5/8" 3/4" 5/8" 3/4"
Length Thread Thread Length Thread Thread
5" ALL56405 ALL56505 18" ALL56418 ALL56518
ALL60166 6" ALL56406 ALL56506 19" ALL56419 ALL56519
ALL60161 7" ALL56407 ALL56507 20" ALL56420 ALL56520
ALL60160 8" ALL56408 ALL56508 21" ALL56421 ALL56521
Part No. Description 9" ALL56409 ALL56509 22" ALL56422 ALL56522
ALL60160 1" Dia. Holes, Sold In Pairs 10" ALL56410 ALL56510 23" — ALL56523
ALL60161 1" Dia. Holes, One Required
ALL60166 3/4" Dia. Holes, Set Of 2 11" ALL56411 ALL56511 24" — ALL56524
12" ALL56412 ALL56512 25" — ALL56525
13" ALL56413 ALL56513 26" — ALL56526
Ford 9" Upper Link Brackets 14" ALL56414 ALL56514 27" — ALL56527
ALL60157 15" ALL56415 ALL56515 28" — ALL56528
Steel brackets are designed 16" ALL56416 ALL56516 29" — ALL56529
to weld to most Ford 9" style 17" ALL56417 ALL56517 30" — ALL56530
center sections. Brackets provide
multiple mounting locations for Unthreaded 72" Suspension Tubes
90/10 shock, upper link, third link 72" long aluminum tubes have a .156" wall.
or pull bar. Set of 2.
Part No. Description
ALL56472 7/8" O.D. Tube For 5/8" Rod Ends
ALL56572 1" O.D. Tube For 3/4" Rod Ends
