SUSPENSION

Limit Chain Clamps 2-Piece Panhard Bars
2-Piece clamp bolts around most Panhard bars
3" O.D. axle tubes providing a lower are formed from
mounting point for a suspension limit 1.250" tubing with 3/4"-16 threads in each end.
chain. Two piece design features For use with 3/4" RH rod ends and clamp-on brackets
a nylon liner allowing clamp to be
installed without removing existing (ALL60180 or ALL60181). Center-to-center length refer-
brake brackets and hubs. ALL68337 HQFH LV ¿JXUHG LQFOXGLQJ URG HQGV 5RG HQGV VROG VHSDUDWHO\
Part No. Description
Part No. Description ALL56146 29" Center-To-Center
ALL68336 Steel ALL56147 30-1/2" Center-To-Center
ALL68337 Aluminum ALL56148 32-3/4" Center-To-Center

Adjustable J-Bar Style Panhard Bars
Bars are formed from
1-Piece Limit Chain Clamps 1-1/2" steel tubing and
1- Piece bearing style clamp slides mount to the pinion rather than the axle tube to maintain
over the end of most 3" O.D. axle adequate driveshaft clearance. J-bars have 3/4" rods ends
tubes providing a lower mounting point and allow up to 2" of adjustment.
for a suspension limit chain. Part No. Drop Description
Part No. Description ALL56155 4" 17-1/2"-19-1/2", 6.2 Lbs.
ALL68332 Steel ALL56156 4" 19-1/2"-21-1/2", 6.2 Lbs.
ALL68333 Aluminum ALL56153 6" 17-1/2"-19-1/2", 6.7 Lbs.
ALL56154 6" 19-1/2"-21-1/2", 7.0 Lbs.
Part No.
Retainer Clamps 2-Piece Replacement Parts Description
Retainer clamp bolts around 3" O.D. ALL99050 Replacement Threaded Adjuster
axle tubes to keep bird cages, floater ALL99052 Adjuster Nut
brackets and limit chain clamps in ALL58072 3/4" Male Moly Rod End
position. Two piece design allows
clamp to be installed without removing
existing brake bracket and hub. Panhard Bar Spacers
Part No. Description Spaces Panhard bar away from rear mount-
ALL68338 Steel ed power steering, brackets, etc. Aluminum
ALL68339 Aluminum or steel. 3/4" I.D.
Part No. Description
ALL56144 Aluminum ALL56145 ALL56144
ALL56145 Steel
Axle Tube Bracket ALL68324
Bracket clamps around 3" wide axle tubes Cut-To-Fit J-Bar Style Panhard Bars
providing a mounting point for a suspension &XW WR ¿W EDU LV
limiter such as a limiting strap or chain. 1" an unwelded kit
wide bracket has tabs with 1/2" holes. offering the ability to build a custom
length J-Bar with up to a 27" long center to center distance,
enough to work with most chassis. Bar is formed from .250" wall
Clamp-On Rings 1-1/2" steel tubing, has a 4" drop, includes a threaded insert and
6WHHO EUDFNHWV EROW WR D[OH WXEHV &KRRVH IURP ¿YH ZLGWKV LQ rod ends.
1-, 2- and 4-bolt designs. Part No. Description
ALL56141 Bar With Standard Rod Ends
ALL56142 Bar With Aircraft Rod Ends
ALL56143 Replacement 3/4"-16 Insert

Track Bar Locator Brackets
Track bar locator brackets are an ideal bolt-on
mounting point for rod ends commonly found on
Panhard bars, track bars or rear axle housing track
ALL60143 ALL60145 locators. For use with 1/2" diameter rod ends.
Part No. Description
ALL60143 1-Bolt, 5/8" Wide Available with a 5/8" or 3/4" bracket mounting hole.
Part No.
Description
ALL60144 2-Bolt, 1" Wide ALL60079 5/8" Hole, 1" Gap
ALL60145 2-Bolt, 1-3/4" Wide ALL60089 3/4" Hole, 1-3/16" Gap
ALL60146 2-Bolt, 2" Wide
ALL60147 4-Bolt, 3" Wide
