SUSPENSION

Steel Radiused Climbing Style Frame Mount Remote Adjustable
Panhard Bar Brackets Panhard Bar Mounts
Steel climbing style Easily adjusted on frame side of
adjuster mounts to Panhard bar, mount has a thread-
chassis square tubing ed shaft and fastens to 1-3/4" di-
and permits Panhard/J- ameter tubing. Standard mount kit
bar adjustment without has 2" of adjustment, drop mount
removing or re-aligning kit has 5" of adjustment. Each turn
spacers or tabs found on of the shaft moves mount .100".
other mounts. Radiused Extension rod may be mounted
slot eliminates the need to ALL60237 in rear window or decking for quick, easy adjust-
re-square the rear end after adjustments. ALL60239 ments from outside of the car. Mounting hardware
Part No. Description and a 3/4" Panhard bar bolt are included.
ALL60236 For 1-1/2" Tubing, Center Mounting Part No. Description
ALL60238 For 1-1/2" Tubing, Inside and Outside Mounting ALL60270 Standard Mount Kit
ALL60237 For 2" Tubing, Center Mounting ALL60273 Drop Mount Kit
ALL60239 For 2" Tubing, Inside and Outside Mounting Replacement Components
Extension Rod With Bushing
ALL60272
Aluminum Radiused Climbing Style Frame ALL60274 For ALL60270/ALL60273 ALL60270 ALL60273
Flange Bearing
Mount Panhard Bar Brackets
Easily adjust your Panhard bar with only Aluminum Panhard Bar Clevis
one wrench! Climbing style adjuster allows
any amount of adjustment without having to Black anodized aluminum clevis clamps
remove or re-align any spacer/tabs. around a chassis tube and connects to
Radiused slot so you don’t have to the 3/4" rod end on the long end of a J-bar
re-square the rear end after adjust- style Panhard bar. After loosening the two ALL60183
PHQWV $OXPLQXP EUDFNHWV ¿W [ Allen bolts, the clamp may be slid up or down
tubing. on the chassis tube to adjust the bar and change roll center.
Part No. Description Part No. Description
Inside/Outside Mounting ALL60182 1-1/2" I.D.
ALL60246 ALL60247
(Most Modifieds and GRT) ALL60183 1-3/4" I.D.
ALL60247 Center/Inside Mounting (Mastersbilt,
Barry Wright, Hughes) Ford 9" Panhard Bar Brackets
ALL60248 Outside /Center Mounting (Rocket)
ALL60249 Center Mounting Ford center section brackets are 1/2"
thick steel or aluminum. Each has four
3/4"-16 mount holes to provide 3.375"
Clamp-On Panhard Bar Brackets ALL60177
ALL60245 of adjustment. Both have dual patterns
Adjustable steel or aluminum brackets DQG PD\ EH ÀLSSHG WR DFFRPPRGDWH
clamp to square tubing, providing multiple right- or left-hand Panhard bars. Both
Panhard bar mounting locations. Brack- DWWDFK ZLWK ¿YH EROWV
ets are tapped for 3/4"-10 bolts. Steel
Part No. Description
brackets have outer holes 5" apart. Alu- ALL60176 Steel Bracket
minum brackets have outer holes 5.5" apart. ALL60177 Aluminum Bracket
Hole measurements are center-to-center.
Part No. Description Double-Sided Ford 9" Panhard Bar Brackets
Steel Brackets
ALL60240 For 2" x 2" Tubing Double-sided, brackets are made of 1/2" steel and accept
ALL60244 For 1-1/2" x 1-1/2" Tubing a right- or left-hand Panhard bar without alteration. Standard
Aluminum Brackets thread (3/4"-16") or 3/4" slotted type.
ALL60243 Straight, 2.5 Lbs., For 2" x 2" Tubing
ALL60245 Angled, 2.0 Lbs., For 2" x 2" Tubing

Internal Screw Style Panhard Bar Adjusters ALL60173 ALL60175
ALL56152
A screw bolt style adjuster is welded inside of
the tube. When welded in place of
current mount, Pan-
Part No. Description
hard bar can be easi- ALL60173 Slotted Double-Sided
ly adjusted by turning ALL60175 Threaded Double-Sided
the screw bolt. Attach ALL99040 Replacement Spacer For ALL60173
Panhard bar to this adjuster with Allstar ALL60183 Clevis (not
included). Rear Panhard mount, 21" tall with 3" of adjustment.
