SUSPENSION

Aluminum Backing Washer ALL64326 Shock Shims
Aluminum washer is designed for use with bump Uniquely designed shock shims are
stop pucks, as a backer washer or many other placed directly onto the shock shaft to
uses. Washer has a 2-1/4" O.D., 5/8" I.D. and is VLPSOLI\ ¿QH WXQLQJ RI WKH FKDVVLV
3/16" thick. without disassembling the shock or
even removing the shock from the
chassis. Kits include a variety of
Bump Stop Shims shim designs and sizes for conve-
Place within the bump stop stack to nient tuning and set-up. ALL64404
limit suspension travel. 2" O.D. shims
Size Starter Kit Standard Kit Deluxe Kit
work with most bump stop bushings. ALL64324 ALL64325 14mm ALL64400 ALL64402 ALL64404
Part No. Description 16mm ALL64440 ALL64442 ALL64444
ALL64324 1/16" Shim
ALL64325 1/8" Shim STARTER KIT
Includes: U-Shaped Shims 1/16" (4 pcs), 1/8" (4 pcs) and 3/8"
Bump Stop Components For Bilstein Shocks (2 pcs); Semi-Solid Shims 1/16" (4 pcs) and 1/8" (4 pcs).
Many bump stop options are available today. These compo- STANDARD KIT
nents are for use with Bilstein shocks. Includes: U-Shaped Shims 1/16" (12 pcs), 1/8" (12 pcs) and
ALL64276 3/8" (6 pcs); Semi-Solid Shims 1/16" (12 pcs) and 1/8" (12 pcs);
Part No. Description
Bump Stop Lower Support 2-Piece Collar Shims 1/2" (2 pcs), 3/4" (2 pcs) and 1" (2 pcs);
ALL64274
For Roller Skate Wheel Stops ALL64277 Storage Case.
ALL64275 Bump Stop Cup DELUXE KIT
Fits The Bilstein Rod End
Rod Guide Protector Puts ALL64275 Includes: U-Shaped Shims 1/16" (12 pcs), 1/8" (24 pcs) and
ALL64276 The Bump Stop Forces Into The 3/8" (10 pcs); Semi-Solid Shims 1/16" (12 pcs) and 1/8" (24 pcs);
Shock Body, Not The Rod Guide Option 2-Piece Collar Shims 1/2" (6 pcs), 3/4" (6 pcs) and 1" (6 pcs);
Splitter Washer Used To Separate Storage Case.
ALL64277
Stops On Stacked Stop Setups
ALL64274
Shock Shim Components
Shock Bump Rubbers U-SHAPED SHIMS
&RQLFDO VKDSHG EXPS UXEEHUV ¿W RQ PRVW VKRFN Designed for quick removal and installation into
shafts up to 16mm to limit shock travel. Bump tight stacks and locations where twisting the shim
rubbers are 2-3/8" tall and have a 2" O.D. base. A into the stack is not an option or when the car is
letter designation is molded in the bottom to identify RQ WKH JURXQG &RPPRQO\ XVHG IRU ¿QH WXQLQJ WKH ALL64412
compound. suspension.
Part No. Description SEMI-SOLID SHIMS
ALL64500 Soft (40 grams) Designed for quick removal providing a secure
ALL64501 Medium (50 grams) installation that will not fall out yet requires 3/4" of
ALL64502 Hard (55 grams)
space to install or remove. Typically installed when ALL64416
WKH YHKLFOH LV RII WKH JURXQG &RPPRQO\ XVHG IRU ¿QH
14mm Bump Stop Kit tuning the suspension.
ALL64360 2-PIECE COLLAR SHIMS
Kit makes it easy to start using bump stops. Designed to attach around the shaft of the
Includes a selection of 20 bump stop shock and secure in place with a zip tie. Commonly
pucks ranging from 50 to 75 durometer, used during initial set-up or to take up a large amount ALL64420
8 backing washers and 16 packer shims of travel.
in a simple plastic carrying case. Description 2-Pack 10-Pack 25-Pack
14mm (.550")
U-Shaped Shim 1/16" — ALL64410 ALL64410-25
U-Shaped Shim 1/8" — ALL64412 ALL64412-25
U-Shaped Shim 3/8" — ALL64414 ALL64414-25
Semi-Solid Shim 1/16" — ALL64416 ALL64416-25
Semi-Solid Shim 1/8" — ALL64418 ALL64418-25
2-Piece Collar Shim Kit 1/2" ALL64420 ALL64420-10 —
Shock Bump Covers 2-Piece Collar Shim Kit 3/4" ALL64422 ALL64422-10 —
These neoprene covers are perfect for protecting 2-Piece Collar Shim Kit 1" ALL64424 ALL64424-10 —
shock shafts and covering bump set ups. Fit 2" O.D. 16mm (.630")
shocks. Not for use with over coil over springs. U-Shaped Shim 1/16" — ALL64450 ALL64450-25
U-Shaped Shim 1/8" — ALL64452 ALL64452-25
Part No. Description U-Shaped Shim 3/8" — ALL64454 ALL64454-25
ALL64216 10" Tall Cover Semi-Solid Shim 1/16" — ALL64456 ALL64456-25
ALL64218 14" Tall Cover Semi-Solid Shim 1/8" — ALL64458 ALL64458-25
2-Piece Collar Shim Kit 1/2" ALL64460 ALL64460-10 —
2-Piece Collar Shim Kit 3/4" ALL64462 ALL64462-10 —
2-Piece Collar Shim Kit 1" ALL64464 ALL64464-10 —
