SUSPENSION

Coil-Over Load Bolt Assembly Extended Length
ALL56074 Upper Spring Cup ALL56125
7KUHDGHG DOXPLQXP EROW LV ORQJ ZLWK ¿QH Commonly used in rear suspensions, cup con-
threads and is commonly used on big bar soft spring nects to jack bolt with a bolt and O-ring to help
cars. Load bolt offers the ability to easily change maintain spring location. Extension sits 5" into the
corner weights, change the center to center distance of spring.
the shock, adjust bump stop distances without adding
shims and adjust ride height without running out of
shock travel. Commonly used with ALL56098 threaded
sleeve. Extended Length “Swiveler”
Part No. Description Spring Cup ALL56079
ALL56075 Replacement Shock End
Extended length cup helps keep spring cen-
tered. Also keeps spring from falling out on some
Upper Spring Cups modern day long drop suspension packages.
Steel cups work with most 5" and 5-1/2"
O.D. springs and either 1" or 1-1/8" jack bolts.
Part No. Description
ALL56114 Standard Cup For 5" Spring Coil Spring Spacer ALL56116
ALL56115 Oversized Cup For 5-1/2" Spring Spacer for 5" racing spring welds into spring
ALL56114 pocket enabling chassis adjustments to street
stock and other race cars that are not allowed
Lightweight Upper Spring Cup to use weight jack bolts or threaded adjusters.
ALL56113 3" tall spacer may be cut to desired height before
installation. Use coil shim spacers ALL56120 and
Lightweight steel cup works with most 5" ALL56121 to make chassis adjustments.
and 5-1/2" O.D. springs and either 1" or 1-1/8"
jack bolts.
Coil Spring Shims

Used with ALL56116, or whenever weight jack bolts are not
Bolt-On Upper Spring Cup allowed, to raise car height for set-up purposes. 5" diameter,
ALL56097 3-5/8" I.D.
Steel upper spring cup bolts to internal thread Part No. Description
jack bolts, keeping spring centered. ALL56120 3/16" Shim
ALL56121 1/8" Shim
“Swiveler” Spring Cups Adjustable Coil Spring Spacers
Swiveler cup is used in place of a standard upper spring plate Spacer adapts racing front springs for use on street stock cars
and weight jack bolt on vehicles using conventional style coil where weight jack bolts are not allowed.
springs. Mono-ball stud mount allows cup to pivot as needed
to prevent binding during suspension travel and requires a
weight jack bolt with a 7/16"-20 internal threaded end for proper
installation.

Welded Style ALL56080 ALL56118 ALL56119
The sleeve and top are welded together on Part No. Description
WKLV XQLW WR ¿W PRVW DSSOLFDWLRQV XVLQJ D FRQ- ALL56118 All Steel Assembly
ventional spring. ALL56119 Steel Sleeve With Aluminum Adjustment Nut

Shock Travel Indicator Kits
Pro-Series Check compression and rebound travel of coil-over
Components bolt together to shocks at a glance. Clamp aluminum bracket portion
select the desired spring top of the kit directly to the coil-over sleeve or shock
plate and sleeve separately to body and attach the other end to the existing shock
build custom size cups. ALL56077 ALL56086 eye bolt or under spring cup. May be used with
Part No. Description most coil-over and non-coil-over shocks. Clamp is
ALL56077 Spring Top Plate For 5" Spring included.
ALL56078 Spring Top Plate For 5-1/2" Spring Part No. Description
ALL56086 3.25" Spring Sleeve ALL60094 Kit For Use With 2-1/2" Spring
ALL56087 3.50" Spring Sleeve Kit For Use With
ALL56088 3.75" Spring Sleeve ALL60095 3" Barrel or 5" Springs
ALL56089 4.00" Spring Sleeve
ALL56085 4.25" Spring Sleeve
