SUSPENSION

Weld-On Shock Brackets Steel Shock Quick Pins
Weld-on shock brackets mount standard and coil-over shocks Steel shock quick pins allow coil-over shocks
with 1/2" I.D. inner bushing or 1/2" rod end to chassis as well as to be quickly serviced or changed. ALL60108 will ALL60108
many other uses. 1/8" thick mild steel brackets include 1/2" bolt, work with Allstar coil-over brackets eliminating the
spacer and locknut. need for a separate bushing. ALL60109 is commonly
NOTCHED TUBE MOUNT used on non-bushing type brackets, but can be used
Bracket is notched for 1-1/2" - 1-3/4" round tubing to create a with Allstar brackets along with bushing. Shock
gusset style mount that welds on three sides. Notched design quick pins are 2-1/2" long and include a hairpin. ALL60109
positions the bracket perpendicular to the tubing at a 90 degree Part No. Description
angle for straight mount and approximately a 75 degree angle ALL60108 Shock Quick Pin With Shoulder
for angled mounts. ALL60109 Shock Quick Pin Without Shoulder
ALL18442 1-5/8" Replacement Hairpins, 2-Pack
STRAIGHT MOUNT
Titanium Shock Quick Pins
Titanium shock quick pins allow coil-over shocks
to be quickly serviced or changed. ALL17120 has
a long shoulder and will work with Allstar coil-over ALL17120
brackets eliminating the need for a separate bush-
ALL60103 ALL60104 ALL60112
Part No. Description ing. ALL17121 is commonly used on non-bushing type
ALL60103 Short Single brackets, but can be used with Allstar brackets
ALL60104 Long Single along with bushing. Shock quick pins are 2-1/2"
ALL60112 Long Two Position long and include a hairpin. ALL17121
ALL60113 Extra Long Three Position ALL60113 Part No. Description
ALL17120 Quick Pin With Shoulder
ALL17121 Quick Pin Without Shoulder
ANGLE MOUNT
Suspension Limiter
Single bushing suspension limiter is common-
ly used on the chassis LR or RR to limit travel
ALL60100 ALL60101 during acceleration “hike up” and control roll
Part No. Description steer. Double bushing limiter is often used on
ALL60100 Left Hand Single the lift bar to control lift bar travel on decelera-
ALL60101 Right Hand Single tion. Bushing design reduces or absorbs shock
when suspension is limited and helps reduce tire
unloading. Top plate is drilled to attach a 1/2" rod
ROUND TUBE MOUNT end when used in a shock mount or for attaching to
Bracket mounts paral- a weight jack bolt with 7/16"-20 internal threads using optional
lel with tubing and has chrome moly stud ALL64304. Clevis has a 3/8" hole for simple
a curved base to cradle attachment to a chain or cables.
tubing. Bracket is typically Part No. Description
mounted above or below tubing. ALL60115 ALL64300 Single Bushing Limiter
Part No. Description ALL60107 ALL64302 Dual Bushing Limiter
ALL60107 Single ALL64304 Chrome Moly Stud With Jam Nut
ALL60115 Three Position

FLAT MOUNT Limiter Chain Kits
%UDFNHW PRXQWV WR D ÀDW VXUIDFH RU VTXDUH WXELQJ Commonly used to limit rear sus-
Part No. Description pension or lift bar travel. Chain kit
ALL60106 Single ALL60106 will accept a bolt or pin or may be
PRGL¿HG WR DFFHSW XS WR D EROW
Shock Spacers Offered in 3/16" or 5/16" x 18" long, ALL64314
chain may be easily cut to required
Steel spacers have a 1/2" I.D. and 3/4" O.D. and can be used length. Shrink sleeve installs over
in a variety of other locations. Package of 2.
chain and when heated with a heat gun shrinks to keep chain in
Part No. Description position, preventing binding or catching.
ALL64280 1/4" Part No. Description
ALL64282 1/2" ALL64312 Limiter Chain Kit, 3/16" x 18" Long
ALL64283 5/8" ALL64314 Limiter Chain Kit, 5/16" x 18" Long
ALL64284 3/4" Related Component
ALL64313 3/16" x 18" Long Chain Only
