SUSPENSION

Poly Bushings Torque Absorber
Poly bushings are designed for racing and work ALL56165
great in pull bars (torque links) and bump stops. Steel torque absorber
Bushings’ progressive rate, starts softly and may be used as the upper
quickly “ramps up.” Bushings provide excellent ALL56374 third link, right rear trailing arm or
performance when loaded offering good abrasion and solvent Panhard bar to increase traction. Measures 7-1/2" between jam
resistance. Sold each. nuts and 10-3/8" end to end. Accepts 3/4" rod ends or suspen-
Part No. Color Hardness O.D. I.D. Height sion tubes.
ALL56369 Green 50 2.25" .75" 1.06" Part No. Description
ALL56370 Purple 60 2.25" .75" 1.06" Replacement Parts
ALL56372 Yellow 75 2.25" .75" 1.06" ALL56164 Thru-Bolt
ALL56373 Blue 80 2.25" .75" 1.06" ALL56166 Bushing (Each)
End Stud
ALL56167
ALL56374 Red 87 2.25" .75" 1.06" ALL99010 Washer
ALL56375 Orange 55 3.375" .75" 2.50" ALL99011 Barrel
ALL56376 Yellow 75 3.375" .75" 2.50" ALL99012 End Cap
ALL56378 Blue 80 3.375" .75" 2.50"
ALL56379 Red 87 3.375" .75" 2.50" Upper Third Links
Aluminum spring-loaded
torque absorbers replace
Bushing Washers the upper solid link on the rear suspension
Required between poly bushings when stacking for extra traction off the corner. Order 3/4"
for optimum performance. rod ends separately.
Part No. Description Part No. Description
ALL99178 Steel Washer For 2.25" Bushings ALL56169 Unit With 1,000 Lb. Red Spring
ALL99179 Aluminum Washer For 2.25" Bushings ALL56171 Unit With 1,600 Lb. Gold Spring
Universal Lift
Third Link Assembly Without Bushings $CT HQT /QFKƂ GFU
ALL56390 ALL68310
Third link assembly designed to increase trac- Steel lift bar has 5th coil
tion to rear tires uses interchangeable poly- adjustments from 26" to 34" in
urethane bushings (sold separately, two 1" increments and
required) to absorb energy under accel- is raised 2-1/2" for
eration and braking. Bushings can be additional center section frame clearance. Accepts 5/8" RH rod
quickly changed to adjust to changing track conditions. ends (not included).
Assembly is 2-1/4" wide x 3" tall and has a 3/4"-16 RH chrome
moly stud for attaching a suspension tube. 3/4" ID inner steel
bushings are stepped to keep link centered in poly bushings. A QC Lift Bar Brackets
good starting point is a 70 durometer acceleration bushing and Brackets mount to Quick Change rearends
90 durometer brake bushing. and accept most popular lift bars. Steel brack-
Part No. Description ets are black, aluminum brackets are plain.
ALL56391 Half Bushing Green, 50 Durometer Package of 2. ALL68317
ALL56392 Half Bushing Orange, 60 Durometer Part No. Description
ALL56393 Half Bushing Yellow, 70 Durometer ALL68314 Steel Lowers With 5/8" Mounting Hole
Steel Lowers With 3/4" Mounting Hole
ALL68315
ALL56394 Half Bushing Blue, 80 Durometer ALL68316 Steel Uppers With 5/8" Mounting Hole
ALL56395 Half Bushing Red, 90 Durometer ALL68317 Aluminum Uppers With 5/8" Mounting Hole
ALL68318 Aluminum Uppers With 3/4" Mounting Hole
Rubber Bushings
Bushings absorb torque from 5th Coil Mount ALL60218
rear end and may also be used as 1-1/2" aluminum bracket bolts in the center of the
replacement in other applications. chassis to mount a 5th coil shock assembly.
Sold each.
Part No. Description 6th Coil Assembly
3" O.D., 1-1/2" Tall, ALL56161 ALL56162
ALL56161 ALL64315
5/16" Shoulder
3" O.D., 1-1/2" Tall, Unit bolts in the center of the chas-
ALL56162
No Shoulder sis to 1-1/2" tubing and the bottom
connects to the front of a lift bar
using the supplied chain. Accepts a
4" tall by 2-1/2" I.D. coil over spring.
