Page 615 - 2019-2020 Racecar Engineering Circle Track Parts and Accessories Catalog

“A” Series Aluminum Smooth Body Shocks “ACF” Series
Twin-tube, “A” Series smooth-body shocks, suited for use on Aluminum Threaded Body
ODWH PRGHOV RSHQ ZKHHOV DQG PRGL¿HGV RIIHU VXSHULRU GULYHU Single Adjustable Shocks
feel and ultimate traction. Fully rebuildable and revalvable, each
shock is serial numbered, dyno tested, and sold complete with Aluminum threaded body, single-adjustable shocks
dyno sheet. Shocks include bearing ends. Simply purchase are engineered for dirt or asphalt late models, asphalt
PROC300 to convert these shocks to coil over units. PRGL¿HGV DQG RWKHU RSHQ ZKHHO FDUV 6KRFNV RIIHU
optimized low-speed control and fade-free performance
that translates to ultimate driver feel.
“A” Series Aluminum Smooth Body Shocks Part No. Stroke Compression Rebound
Collapsed Extended Damping PROACF74.57-12R 7" 4.5 7-12
Part No. Stroke Length Length Comp./Rebound PROACF756-11R 7" 6 6-11
PROA640B 6" 11.50" 17.50" 4/4 PROACF767-12R 7" 6 7-12
PROA646B 6" 11.50" 17.50" 4/6
PROA650B 6" 11.50" 17.50" 5/5
PROA653B 6" 11.50" 17.50" 5/3
PROA740B 7" 12.50" 19.50" 4/4
PROA745B 7" 12.50" 19.50" 4/5 Coil-Over Kits For “ACF” Series
PROA746B 7" 12.50" 19.50" 4/6 Part No. Description
PROA750B 7" 12.50" 19.50" 5/5 Coil-Over Kit, 2-1/2",
PROA751B 7" 12.50" 19.50" 5/1 PROC352 Flat Spring Seat
PROA752B 7" 12.50" 19.50" 5/2 Coil-Over Kit, 2-1/2",
PROA754B 7" 12.50" 19.50" 5/4 PROC353 Tapered Spring Seat
PROA760B 7" 12.50" 19.50" 6/6
PROA762B 7" 12.50" 19.50" 6/2
PROA763B 7" 12.50" 19.50" 6/3 Shock Absorber Hardware
PROA770B 7" 12.50" 19.50" 7/7 A wide variety of replacement hardware is offered for both
PROA838B 8" 13.50" 21.50" 3/8 aluminum and steel-body shock absorbers.
PROA846B 8" 13.50" 21.50" 4/6
PROA847B 8" 13.50" 21.50" 4/7
PROA848B 8" 13.50" 21.50" 4/8
PROA849B 8" 13.50" 21.50" 4/9
PROA9310B 9" 14.50" 23.50" 3/10
PROA938B 9" 14.50" 23.50" 3/8
PROA939B 9" 14.50" 23.50" 3/9
PROA940B 9" 14.50" 23.50" 4/4 PROB200A PROB212 PROB212-1 PROWB200 PROC305
PROA945B 9" 14.50" 23.50" 4/5
PROA946B 9" 14.50" 23.50" 4/6 Part No. Description
Aluminum Bearing End,
PROA947B 9" 14.50" 23.50" 4/7 PROB200A 2" Body Coil-Over Shocks, 1/2" I.D. Hole
PROA948B 9" 14.50" 23.50" 4/8
PROA950B 9" 14.50" 23.50" 5/5 PROB212 Standard Billet Rod End, ACF Shocks
PROA956B 9" 14.50" 23.50" 5/6 PROB212-1 1" Extended Billet Rod End, ACF Shocks
PROA957B 9" 14.50" 23.50" 5/7 PROB275 Aluminum Bearing End,
PROA960B 9" 14.50" 23.50" 6/6 1.63" Body Coil-Over Shocks, 1/2" I.D. Hole
PROC305 Coil-Over Snap Ring, 2" Body Shocks
PROC510 1" Shock Extension
PROC520 2" Shock Extension
Coil-Over Kit PROC300 PROS500 Eye Ring, Screw-On With 1/2" Sleeve
Aluminum coil-over kit for reg u lar size PROS506 Stud Mount, Straight Threaded Stem-Type Shock End
2" body “A” series coil-over shocks.
PROS512/514 GM Bar Pin Assembly, 9/16"
PROWB200 Steel Bearing End, 2" Body Coil-Over Shocks, 1/2" I.D. Hole
PROZ902 Spanner Wrench, Allows Easy Coil-Over Adjustments
AFC10157 Large Diaper Pin

STEVE PEEDEN BLAINE HENDRICK JOHNNY B
