S7-63 Mini Circuit Breaker
Tripping characteristics curve (Table 1).
Current limiting characteristics (Table 2).
S7-63 mini circuit breaker has a high current limiting ability to maximize limit the short circuit
caused by the destructive energy.
Wiring, for 25mm² wires (Table 4), torque is 2.0N•m (Table 4)
Rated current Copper conductors nominal cross-sectional area
1-6 1
10 1.5
16、20 2.5
25 4
32 6
40、50 10
63 16
Overall and installation dimension
Type 7
