Chief Architect X10 Reference Manual

located within and on the same floor as the The Make Hole(s) Around Building(s)
Terrain Perimeter. The shape of these holes edit tool creates a Terrain Feature polyline
follow the exterior surfaces of the walls and with Make Hole checked in its specification
will automatically update if any of those dialog around each building on the same
walls are moved.
floor level as the Terrain Perimeter. See
If you prefer to manually control the “Terrain Feature Specification Dialog” on
holes around structures, select the page 1225.
Terrain Perimeter and click the Make The Terrain Hole tool allows you to
Terrain Hole(s) Around Building(s) edit draw Terrain Feature polylines with
button. See “Terrain Perimeter” on page Make Hole specified, as well.
1200.

Garden Bed Tools

Select Terrain> Garden Bed to Kidney Shaped Garden Bed
access tools that can be used to place
garden bed features in your terrain. You can draw a kidney shaped garden
bed with this tool. See “Kidney
Polyline Garden Bed Shaped Features” on page 1209.
Garden Beds are basically Terrain Features
This tool draws a garden bed with with material and height attributes typical of
straight sides and four right angles.
See “Rectangular Features” on page 1209. planting beds. See “Terrain Feature Tools”
on page 1208.
Round Garden Bed You can specify a Garden Bed’s material and
height in its Terrain Feature Specification
Use this tool to draw garden beds with dialog. See “Terrain Feature Specification
rounded edges and smoothly curved Dialog” on page 1225.
corners. See “Spline Feature” on page 1209.
In addition, you can choose to distribute
copies of a plant image within a Garden Bed.
See “Distributed Plant Panel” on page 1226.

Water Feature Tools

Select Terrain> Water Feature to bodies of water. See “Terrain Feature Tools”
access tools for drawing ponds and on page 1208.
streams in your terrain.
Similarly, Streams are Terrain Curbs with a
Ponds are basically Terrain Features with water material. See “Terrain Wall and Curb
material and height attributes typical of Tools” on page 1212.

1210
