Chief Architect X10 Reference Manual

assigned a different Room Type in its Room not created. See “Locating Intersections” on
Specification dialog. When this box is page 794.
checked, the room label’s display will be Select the desired Skylight Ceiling
enabled when the Room Type is changed 6 Hole Default behavior.
from “Unspecified”. See “General Panel” on
page 435. •If you select Skylights Automatically
Generate Ceiling Holes, the program
5 Check Automatically Place Roof automatically generates a ceiling hole for
Intersection Points to automatically a new skylight.
generate temporary CAD points that
correspond to roof plane intersection points. • Select Manually Edit Ceiling Hole Poly-
When unchecked, these temporary points are lines to create your own ceiling holes.
CAD Panel

The CAD panel contains settings that define
how CAD blocks, Sun Angles and other CAD
and CAD-based objects behave.

1 The CAD Blocks settings determine blocks. See “CAD Blocks” on page 326.
the default fill style behavior for CAD

122
