Chief Architect X10 Reference Manual

1 Rotate/Resize About defines the point To resize a CAD object about a current point,
about which an object or a group of select the Resize Edit Type.
objects rotates or resizes. See “Rotate/Resize This function can also be accessed by
About” on page 167.
selecting Edit> Edit Behaviors>
• Select Object Center to rotate or resize
the selection about its center point. Object Resize . See “Defaults, Preferences, and
Center is the default setting. Edit Behaviors” on page 208.
• Select Current Point to rotate the object
about the current CAD point instead.

Concentric Resize About
Resize Current Point

Rotate about Rotate about • Rotate Jump defines the angles an object
Object Center Current Point or group of objects jumps to as it is
rotated. When this value is set to 0°, the

126
