Chief Architect X10 Reference Manual
1 Options - length of camera and cross section/eleva-
tion lines of sight. See “Creating Camera
• Specify the Objects in History, which is Views” on page 1049.
the number of Extension Line Anchors • Specify the Maximum Bump Distance,
that can display at one time. which is the distance that a selected object
• Specify the Snap Distance, which is how must be dragged to override bumping and
far the cursor can be from a snap point for move past an obstructing object.
the snap to occur. This value is measured • Check Snap Cabinets After Paste to
in screen pixels; the default value is 12. make the cabinets snap together after you
When working with very small objects, paste them.
you may find it helpful to reduce this • Check Always Snap Walls on Allowed
value; when working with very large Angles to limit walls to Allowed Angles.
objects, it may be helpful to increase it. When unchecked, Object Snaps can over-
This setting also controls the minimum ride Angle Snaps, allowing walls to snap
128
