Chief Architect X10 Reference Manual
Image Panel
1 General - or click the Library button to choose a
CAD block from the Library Browser.
• The path and name of the selected plant’s Specify the Size/Elevation of the plant
Image File displays here. 2 image, as seen in 3D views.
• Click Browse to specify the saved loca- • Specify the Height and Width of the
tion on your computer of the image that image.
represents the plant in 3D views.
•When Retain Aspect Ratio of is checked,
• A number of 2D Plant Symbols are avail- if you change either the Height or Width,
able to represent the image in floor plan the other value changes to maintain this
view. Select one from the drop-down list
