Chief Architect X10 Reference Manual

Display Options dialog. See “Layer Sprinkler Heads are counted in the Materials
Attributes” on page 185. List, as is the total length of Sprinkler Lines
and Splines. See “Materials Lists” on page
In floor plan view, Sprinkler Head symbols 1263.
indicate the spray angle.
Editing Sprinklers
90° 180° 360°
Spray Spray Spray Sprinklers can be edited much the way other
objects from the library can: using their edit
handles, edit tools, and in their specification
dialog. See “Editing Library Objects” on
page 944.

Sprinkler Line Sprinkler Spline The elevation of a sprinkler can be
edited in cross section/elevation views.
Sprinkler head display in 3D views;
however, Sprinkler Lines and Splines do not.

Sprinkler Specification Dialog

To open the Sprinkler Specification This dialog an example of a Symbol Object
dialog, select a sprinkler or group of Specification dialog. See “Symbol Object
sprinklers and click the Open Object edit Specification Dialogs” on page 947.
button. You can also double-click the sprin-
kler(s) using the Select Objects tool.

1260
