Chief Architect X10 Reference Manual

Project Management drop-down in the toolbars. See “Drop-
Down Controls” on page 140.
• Icons in the Project Browser now denote
views and layout pages that are currently • The Active Annotation Set Control
open. See “Project Browser” on page 75. drop-down was removed from the default
toolbars. See “Drop-Down Controls” on
• Multiple views in the same Project page 140.
Browser folder can now be selected as a
group and then managed using their • The Control drop-down lists in the tool-
shared contextual menu. See “Project bars now feature a tool icon for easier
Browser” on page 75. recognition. See “Drop-Down Controls”
on page 140.
• Saved views, plan files, and layout files
can now be closed using the contextual
menu in the Project Browser. See “Proj- View and Window Tools
ect Browser” on page 75. • Plan views can now be saved, and multi-
• The maximum number of Closet room ple plan views can be open at the same
boxes that can be created by the Space time. See “Plan Views” on page 154.
• Improved how the Reference and Snap
Planning Assistant has been
increased to 5. See “Space Planning” on Grid lines display when zoomed out. See
page 80. “Grid Snaps” on page 172.
• The title bars and tabs of Wall Detail
Preferences and views now state the floor that the associ-
Default Settings ated wall is drawn on. See “Working in
Multiple Views” on page 157.
• Camera Defaults, Door Defaults, Base,
Wall, and Full Height Cabinet Defaults, • Each view window’s tab now features an
Dimension Defaults, and Text, Callout, icon indicating its type of view. See
and Marker Defaults can now be edited in “Working in Multiple Views” on page
groups. See “Default Settings” on page 157.
86. • The File Save and View Save message
prompts now feature an icon indicating
• N e w Selected Edge Handle Fill color
setting. See “Colors Panel” on page 107. the type of file or view being closed. See
“Closing Views and Files” on page 164.
• Obsolete Command Flushing setting
removed from the Preferences dialog. See • N e w Close All 3D Views command.
“Render Panel” on page 134. See “Closing Views and Files” on page
• Obsolete Categories panel removed from 164.
the Preferences dialog.
Creating Objects
Toolbars and Hotkeys • The obsolete Copy Region as Picture tool
• N e w Saved Plan View Control and was removed from the software.
Active Dimension Defaults Control

1370
