New and Improved Features by Chapter

• N e w Move Left and Move Right buttons • N e w Find Object in Plan e d i t t o o l
for cabinet face items. See “Front/Sides/ for line items in schedules and the Mate-
Back Panel” on page 632.
rials List. See “Find Object in Plan” on
• Option to show cabinet face items as page 674.
open was moved to the FRONT/SIDES/
BACK panel of the Cabinet Specification • N e w Open Row Object(s) edit tool
dialog. See “Front/Sides/Back Panel” on for line items in schedules and the Mate-
page 632. rials List. See “Open Row Object(s)” on
page 670.
• N e w Percent Open setting for cabinet
doors and drawers. See “Front/Sides/ • N e w Use Default Formatting option for
Back Panel” on page 632. custom object labels with macros. See
“Default Label Formatting” on page 681.
• Special cabinet shelf and rollout storage
and organization objects can now be • The Supplier for most objects can now be
inserted into cabinets. See “Rollout set in their specification dialog rather
Shelves and Storage” on page 616. than in the Components dialog. See
“Object Information Panel” on page 685.
• Shelves and Partitions can now be
included in schedules. See “Cabinet • N e w Column to Include for Supplier in
Schedules” on page 646. all schedules except Framing and Room
Finish. See “Columns and Objects to
• Improved how cabinet fillers are named Include” on page 672.
in cabinet schedules. See “Cabinet
Schedules” on page 646. • N e w Columns to Include for energy
value information in Door and Window
Electrical Schedules. See “Columns and Objects to
Include” on page 672.
• Wall mounted electrical objects placed
from the Library now use the Height • Include Type is no longer available in the
value saved in their specification dialog Electrical Schedule Specification dialog.
instead of in the Electrical Defaults dia- See “Label Panel” on page 679.
log. See “Placing Electrical Objects” on • Automatic labels for Added Lights have
page 653. been removed. See “Displaying Lights”
• Retired the deprecated Custom Light on page 1093.
Intensity dialog. See “Light Data Panel”
on page 661. Foundations
• Brick ledge lines are now drawn in floor
Schedules and Object Labels plan view. See “Displaying Foundations”
• New Custom Fields allow you to easily on page 693.
create custom Schedule columns. See
“Custom Fields” on page 673. Stairs, Ramps, and Landings
• Stair Railings and Railings at Walls can
now be specified independent of one

1373
