Chief Architect X10 Reference Manual

• The version X10 template plans have a which you can now specify. See “Dimen-
variety of new Room Types. See “Struc- sion Panel for Angular Dimensions” on
ture Panel” on page 436. page 482.
• The Include in Schedule check box is
now in the Room Type Defaults dialogs. Text, Callouts, and Markers
See “General Panel” on page 435. • Text can now be pasted directly into cross
• N e w Select and Clear Transferrable section/elevation views. See “Pasting
buttons in the Match Properties dialog. into a View” on page 508.
See “Match Properties Dialog” on page
281. Doors and Windows
• New properties for electrical objects were • Wall surface lines now display for Door-
added to the Match Properties dialog. See ways and can be displayed or suppressed
“Match Properties Dialog” on page 281. for all types of doors. See “In Plan
• When Select Room Before Wall in 3D is Views” on page 535.
unchecked in the Preferences dialog, • Windows can now display Header Lines
rooms can now be selected in 3D views and the “Doors, Headers” layer was
renamed “Opening Header Lines”. See
using the Select Next Object edit
tool. See “Select Room Before Wall in “In Plan View” on page 572.
3D” on page 418. • New “Glass Slab” Door Style. The
“Glass” Style was renamed “Glass
Dimensions Panel”. See “General Panel” on page 545.

• N e w Reach settings in the Auto Story • New settings to control the display of
Pole Dimension Defaults dialog. See doors and windows in pony walls. See
“General Panel” on page 460. “Pony Wall Defaults” on page 342.
• Doors and Doorways placed in Solid
• Auto Story Pole dimensions now Railings now have a FRAMING panel in
locate the tops of shed roofs. See “Auto their specification dialog and can display
Story Pole Dimensions” on page 471.
jambs. See “Framing Panel” on page 556
• Improved the feedback of snap indicators and “Jamb Panel” on page 552.
while drawing dimension lines. See “The • Removed abbreviations from Window
Manually Drawn Dimension Tools” on Types reported by the %type% macro.
page 465.
See “Text Macros” on page 522.
• The bottom strings of Auto NKBA Ele-
vation Dimensions no longer locate Cabinets
doors. See “NKBA® Auto Elevation • Cabinet front items can now be selected
Dimensions” on page 470. by right-clicking in the Cabinet
Specification dialog preview. See “Cabi-
• Improved how Angular Dimensions net Specification Dialog” on page 627.
are linked to a Saved Dimension Default,

1372
