Chief Architect X10 Reference Manual
• Quadrant Bearings - Measured from a • Pitch - Defined as a ratio of vertical rise
vertical line representing North/ South, to horizontal run. In Imperial units, the
Quadrant Bearings use directional bear- run is always 12”; in metric units it is
ings in their measurements. Useful for site 1000 mm. Useful for roofs.
drawings.
Quadrant and Azimuth Bearings are affected
• Azimuth Bearings - Measured from a
line drawn straight up from the angle’s by the orientation of the North Pointer ,
vertex (ie, North on a site plan). Useful if one is present in the current plan. See
for site drawings, Azimuth Bearings use “North Pointer” on page 1098.
degrees, minutes, and seconds in their
measurements.
138
