Chief Architect X10 Reference Manual

Rooms Below Staircases

Rooms such as closets or storage areas are • On the FILL STYLE panel, select None
commonly located beneath staircases. (Transparent) so the walls and other
objects under the stairs can be seen.
To create a room below a staircase 2. On the same floor as the staircase, draw

1. Draw a staircase, select it, and click the the Interior Walls under them, fol-
Open Object edit button to open the lowing their shape.
Staircase Specification dialog. 3. Reposition the walls as needed, making
• If Winders are specified for this stair- sure that each is entirely under the stairs.
case, set Max Tread Contraction to 2" 4. The wall at the foot of the stairs should
on the STYLE panel to allow walls to be be placed no closer to the bottom than
built entirely under the staircase. the second step.
5. Add a door and specify the Room Type.

752
