Chief Architect X10 Reference Manual

• Specify the Tread Depth, or run, of each Lock Bottom radio button, above, and
stair tread in the selected section. To lock click OK.
this value, check Lock Tread Depth, • Define the Top Height, the height of the
above. stair section’s top edge. To lock this
If a landing is created between two stair value, click the radio button to the left of
sections and one of them has locked tread the section’s number, then click the Lock
depth, the resulting staircase also has locked Top radio button, above, and click OK.
tread depth. Any landings or sections • Define the Riser Height, the height of
connected to this new staircase adjust to meet the risers in each stair section.
it and then have locked tread depth as well.
• Check Winders to specify the Selected
• Define the number of Treads in a stair Section, including subsections, as wind-
section or subsection. To lock this value, ers. See “Winders” on page 745.
select Lock Number of Treads, above.
• Define the Bottom Height, the height of 4 A preview of the selected staircase
displays on the right side of the panel.
the stair section’s bottom edge. To lock If the staircase includes any landings, only
this value, click the radio button to the the section that was selected when the dialog
left of the section’s number, then click the was opened will display. See “Dialog
Preview Panes” on page 42.

756
