Staircase Specification Dialog

assigned to the “Stairs & Ramps, Details” assigned to the “Stairs & Ramps, Details”
layer and a transparent fill. layer and a transparent fill.
• Select Nothing to hide the display of the • Select Nothing to hide the display of the
staircase after the breakline entirely. staircase before the breakline entirely.
3 The Floor Above Display settings
control the appearance of the portion of Note: Stairs located on the floor below can
the staircase located Before the Breakline, only be seen if a Stairwell room is defined
as seen from the floor above the stairs. above them. See “Creating a Stairwell” on
page 750.
• Select Normal to display the staircase
before the breakline using the same Line A preview of the selected staircase
and Fill Styles as the portion located after 4 displays on the right side of the panel.
the breakline. If the staircase includes any landings, only
• Select Outline to display the staircase the section that was selected when the dialog
before the breakline using the Line Style was opened will display. See “Dialog
Preview Panes” on page 42.

Railing Panel
By default, the settings on the RAILING panel This panel is also found in the Ramp and
also affect the railings on any landings Landing Specification dialogs.
attached to the selected staircase or ramp.
See “Landings” on page 737.
