Chief Architect X10 Reference Manual

Specification dialog. See “Rails Panel” on Line Style Panel
page 407.
The settings on the LINE STYLE panel are
Four unique Handrail at Wall Options are available for a variety of other objects in the
available on this panel for stairs: program. For information about these
settings, see “Line Style Panel” on page 301.

Fill Style Panel
The settings on the FILL STYLE panel affect
the appearance of the selected staircase in
floor plan view. For information about these
• Specify the Extend Bottom value, which settings, see “Fill Style Panel” on page 315.
is the distance that the bottom of each
railing section extends past the bottom Materials Panel
riser of its corresponding stair section.
The settings on the MATERIALS panel affect
• Specify the Extend Top value, which is
the distance that the top of each railing the appearance of the selected staircase in 3D
section extends past the top riser of its views and are available for a variety of
corresponding stair section. objects throughout the program. For
information about these settings, see
• Check Add Return at Bottom to add a “Materials Panel” on page 1017.
return to the wall at the bottom end of all
railing sections that are against a wall. The settings on this panel will also affect the
materials applied to any landings attached to
• Check Add Return at Top to add a the selected staircase. See “Landings” on
return to the wall at the top end of all rail- page 737.
ing sections that are against a wall.

By default, the settings on the RAILS panel Arrow Panel
will also affect the appearance of railings on
any landings attached to the selected The settings on the ARROW panel control the
staircase. See “Landings” on page 737. appearance of the selected staircase’s
direction arrow in floor plan view. See “In
Floor Plan View” on page 732.

For information about these settings, see
“Arrow Panel” on page 303.

Ramp Specification Dialog

Ramps can be defined with the select one or more ramps and click the Open
greatest accuracy using the Ramp Object edit button or double-click a ramp
Specification dialog. To open this dialog,

766
