Stair Landing Specification Dialog

By default, the settings on this panel will also program. For information about these
affect the appearance of railings on any settings, see “Line Style Panel” on page 301.
landings attached to the selected ramp. See
“Landings” on page 737. Fill Style Panel

Selected Line Panel The settings on the FILL STYLE panel affect
the appearance of the selected ramp in floor
The SELECTED LINE panel is available when plan view. For information about these
the selected ramp section is straight as settings, see “Fill Style Panel” on page 315.
opposed to curved. See “Selected Edge” on
page 214. Materials Panel
The settings on this panel are available for a The settings on the MATERIALS panel affect
variety of other objects in the program. For the appearance of the selected ramp in 3D
information about the settings on this panel, views and are available for a variety of
see “Line Panel” on page 300. objects throughout the program. For
information about these settings, see
Selected Arc Panel “Materials Panel” on page 1017.
The SELECTED ARC panel is available only The settings on this panel will also affect the
when the selected ramp section has been materials applied to any landings attached to
converted to an arc. See “Curved Stairs and the selected ramp. See “Landings” on page
Ramps” on page 730. 737.
The settings on this panel are available for a
variety of other objects in the program. For Arrow Panel
information about these settings, see “Arc The settings on the ARROW panel control the
Panel” on page 309. appearance of the selected ramp’s direction
arrow in floor plan view. See “In Floor Plan
Line Style Panel View” on page 732.
The settings on the LINE STYLE panel are For information about these settings, see
available for a variety of other objects in the “Arrow Panel” on page 303.

Stair Landing Specification Dialog

Select a landing and click the Open Landing Specification dialog. See
Object edit button to open the Stair “Landings” on page 737.

769
