Architectural Blocks, Sub-Objects, and Components

To select a sub-object required, the architectural block must be
exploded.
1. Click the Select Objects button,
then click on the sub-object that you Components
would like to edit.
You can view and modify the
2. With the architectural block selected,
components of an architectural block
click the Select Next Object e d i t or group of blocks in the Components
button or press the Tab key. dialog. The Components dialog lists all the
The selection switches to the individual sub-objects that comprise an architectural
object and it can be edited using its edit block, as well as the components that make
handles, edit toolbar and specification up each sub-object.
dialog. To open the Components dialog, select an
The options for editing a sub-object may be architectural block and click the
more restricted than if the object were Components edit button. See
independent. If more extensive editing is “Components Dialog” on page 1284.

975
