Page 58 - CAT-SAFETOP-2019-ENGLISH

AUTO DARKENING WELDING HELMETS

IMPROVED
FILTER
70565 PROFISHELL

Ergonomic and reliable technology.
Auto-darkening welding helmet with side adjustment screw, fitted with
electro-optical filters (the lens will automatically darken), two sensors
and a photoelectric cell with adjustable state shade, sensitivity and
delay control, with viewing area of 100x41 mm.
aLight state shade DIN4; Dark state shade DIN 9/13.
aViewing area: 100x41 mm.
aSwitching time: <1 ms room temperature.
aUV/IR protection DIN 16.
aDelay time: 0,1-10 sg (internal adjustment).
aTIG welding: at least 10A.
aOuter material: High impacted nylon.
aPower supply: Solar cell and lithium batteries.

Certificate: EN 175 / EN 379
Packing: 1 pc / 6 pcs (carton)

PROFISHELL SPARE PARTS

INSIDE COVER LENS 105x47x1 mm REF. 71529
OUTSIDE COVER LENS 104x115x1 mm REF. 71526
HEADGEAR REF. 70570
CASSETTE 4-9/13 REF. 71165

70561 PROFISHELL ONE

The best price-features relationship.
Auto-darkening welding helmet powered by solar cells, with PP black
housing in matte finish.
aCartridge size: 110x90x9 mm, certified for protection against high
speed particles.
aViewing area: 96x39 mm.
aShade state DIN 4/9-13 variable (external).
aGrinding funtion: DIN 4 (external).
aSensitivity: stepless variable (internal).
aSwitching time: <1/30000 s (ANSI +23º)
aDelay time: 0,1-1,0 s (variable, internal).
aPower supply: Solar cell, no Li-Battery change required.
aUV/IR protection: DIN 16 (permanent).
aWorking temperature: -10ºC - 60ºC.

Certificate: EN 175 / EN 379
Packing: 1 pc / 6 pcs (carton)

PROFISHELL ONE SPARE PARTS

INSIDE COVER LENS 105x47x1 mm REF. 71529
OUTSIDE COVER LENS 114x90x1 mm REF. 71530
HEADGEAR REF. 70570
CASSETE 4-9/13 REF. 71161

56
