Stainless Steel Mounted UNIARCH

Introduction

Before You Get Started

Tools needed for installation:

tape measure (25 foot or greater) tin snips
level safety glasses
miscellaneous hand tools work gloves
ladder 2 large pipe wrenches

Equipment included:

UNIARCH leg weldment (typical) 2
Accessory box with Coupling assemblies 1
Accessory box contents (Stainless Steel Fittings):

2744 Barbed hose fitting stainless steel 3/4 MNPT x 3/4 barb hose
1MANUL230 UNIACH owners manual
1TEE-SS150 1-1/2 NPT tee, 304 stainless steel
1REDUC-SS300 1-1/2 x 3/4 reducer bushing, 304 stainless steel
1NIPPL-SS150 1-1/2 NPT closed nipple, 304 stainless steel

1UNION-SS850 1-1/2 NPT union, 304 stainless steel
1FSTNR-SH850 7/16-14 x 4” stainless steel (8)
1CLAMP310 1-1/2” clamp for 1-1/2” pipe (4)
