1063 PROGRAMMING AND OPERATION

Chapter 4 Operator Interface/Advanced Configuration

Setup / Advanced Configuration

Advanced Configuration / Application Configuration
NAMED 1 - 8

NAMED ON or OFF ON ON OFF WP
YES / NO FS / FE 000 FS / FE 000 FS / FE 000 YES / NO
Name of OUTPUT. Toggles between Toggles between FS and FE. Toggles between Toggles between
Typically renamed YES and NO. FS stands for “From Start”. FE stands for FS and FE. YES and NO.
to match the If set to YES, the “From End”. FS stands for If set to YES, the
application. Output will function The three zeros are the “Measured in “From Start”. FE Output will turn off
with that Inches”. stands for “From during B/F
application. End”. (Butterfly) in
Each NAMED 1 – 8 have two ON motion to flush
positions. The three zeros
are the “Measured pump.
in Inches”.
Each NAMED 1 –
8 have one OFF
position.
They all turn OFF
at the end of
application.

MISCELLANEOUS 1 - 7
MISC NAMED ON or OFF ON OFF PFFA WP
YES / NO FS / FE 000 FS / FE 000 YES / NO YES / NO
Name of OUTPUT. Toggles between Toggles between Toggles between Toggles between Toggles between
Typically renamed YES and NO. FS and FE. FS and FE. YES and NO. YES and NO.
to match the If set to YES, the FS stands for FS stands for PFFA stands for If set to YES, the
application. Output will function “From Start”. FE “From Start”. FE “Position From Output will turn off
with that stands for “From stands for “From Front Always”. during B/F
application. End”. End”. (Butterfly) in
The three zeros The three zeros motion to flush
are the “Measured are the “Measured pump.
in Inches”. in Inches”.
Each MISC 1 – 7 Each MISC 1 - 7
have one ON have one OFF
position. position.

1MANUL294 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 4-3
