AUXILIARY ALUMINUM ARCH

Introduction

Before You Get Started

Tools needed for installation:
hammer drill with 1/2” bit 25 foot extension cord

tape measure (25 foot or greater) tin snips
level safety glasses
miscellaneous hand tools work gloves
ladder

Equipment included:
Single Aluminum Arch leg assembly (typical) 2

Single Aluminum Arch top beam assembly 1
Accessory box 1

Accessory box contents:
1/2” lock washer 8
1/2-13 x 5” HHCS CAD 8
1/2-13 x 3” cement quick lag bolts 4
1/2-13 regular nut CAD 8

Note: If you have purchased an arch configuration to apply chemicals to the vehicles, you will
require a method to mix and/or deliver chemicals to the arch. If you do not have the means
to do such, Belanger, Inc. offers the “AFIS” to handle this situation. See options above.

®
