FOAMING PODS

Introduction

Before You Get Started

Tools Needed for Installation:

Work gloves #25 Drill Bit
Safety glasses Tin snips
Tape measure (25 foot or greater) Miscellaneous hand tools
10-24 Tap Drill

Things You Need To Know Before You Get Started:

You should allow for two different scenarios:
• The standard Triple-Foam will fire all of the outputs at the same time
• Optional configuration to fire either a single foam, double foam or triple foam

• Single: ports #1, #2 and #6 fire together.
• Double: ports #3, #4, #5 and #8 fire together.
• Triple: all ports fire together.

Single Foam: Ports #1, #2 and #6
Double Foam: Ports #3, #4, #5 and #8

Direction
Of Travel
