Page 40 - schluter 2019 Price List DJC final(1)_Neat

FINISH ING & EDGE-PRO TECTION PRO FILES FOR WALL S & COUNTE R T OP S

®
Schluter -QUADEC-K
®
Schluter -QUADEC-K is a variant of the
QUADEC profile without an anchoring leg.
It features an open cavity that is filled with
thin-set mortar to secure the profile in the
assembly. Alternatively, the profile may be
installed with an adhesive such as 12.5 mm - 1/2"
Schluter -KERDI-FIX. QUADEC-K is installed in
®
wall applications (e.g., wainscotings and bases) 12.5 mm - 1/2"
with coverings up to 1/2" (12.5 mm) thick.
The profile is particularly suited for finishing edges
in retrofit applications, such as thin porcelain
panel installation over existing wall tiles.

Schluter -QUADEC-K
®
Length =
2.5 m - 8' 2-1/2" Satin anodized aluminum (AE) Polished chrome anod. alu. (ACG)
H = $ / Inside/outside $ / $ / $ / Inside/outside $ / $ /
mm - in. Profile Length corner Unit Connector Unit Profile Length corner Unit Connector Unit
12.5 - 1/2 Q 125 AE K 18.75 EV/Q 125 AE 7.37 V/RO 125 2.23 Q 125 ACG K 22.14 EV/Q 125 ACG 8.75 V/RO 125 2.23

Length =
2.5 m - 8' 2-1/2" Satin nickel anod. alu. (AT) Brushed antique bronze anod. alu. (ABGB)
H = $ / Inside/outside $ / $ / $ / Inside/outside $ / $ /
mm - in. Profile Length corner Unit Connector Unit Profile Length corner Unit Connector Unit
12.5 - 1/2 Q 125 AT K 20.50 EV/Q 125 AT 7.23 V/RO 125 2.23 Q 125 ABGB K 24.22 EV/Q 125 ABGB 13.38 V/RO 125 2.23

Schluter -QUADEC-FS
®
Schluter -QUADEC-FS is a double-rail feature
®
strip profile that features a recessed section to
which field or accent tile is bonded. The profile
can be used to produce accents in tile fields on
walls, chair rails, and various other decorative 50 mm - 2" = H 72 mm - 2-7/8"
applications. The profile can be combined with
®
the Schluter -QUADEC (page 34) finishing and
edge-protection profile. QUADEC-FS features
integrated joint spacers that establish defined
joint cavities between the accent tile and the
profile.
Inside/outside corner /
End cap (EV/)
Note: The universal accessory piece can
be used to produce a 90° inside corner, 90°
outside corner, and end cap.

Schluter -QUADEC-FS
®
Length =
2.5 m - 8' 2-1/2" Satin anodized aluminum (AE) Polished chrome anod. alu. (ACG)
H = $ / Inside/outside $ / $ / Inside/outside $ /
mm - in. Profile Length corner Unit Profile Length corner Unit
8 - 5/16 QF8/50 AE 33.04 EV/QF8/50 AE 22.06 QF8/50 ACG 43.94 EV/QF8/50 ACG 26.12

Length =
2.5 m - 8' 2-1/2" Satin nickel anod. alu. (AT) Brushed antique bronze anod. alu. (ABGB)
H = $ / Inside/outside $ / $ / Inside/outside $ /
mm - in. Profile Length corner Unit Profile Length corner Unit
8 - 5/16 QF8/50 AT 34.99 EV/QF8/50 AT 22.06 QF8/50 ABGB 47.41 EV/QF8/50 ABGB 28.31

38 Customer Service: 800-472-4588
