Page 495 - 2018 National Home Improvement

2018 National Home Improvement Estimator, All Rights Reserved Page 396

Heating System Renovations

Remove residential heating system components. Includes hauling components from the site. No
salvage value assumed. Costs will be higher if components include detectable friable asbestos or if
access to the site is limited. If the furnace or ductwork is wrapped in asbestos, you may be legally
required to follow asbestos abatement procedures. This may require the services of a specialized
asbestos abatement contractor.
Gravity feed furnace and plenum P1@5.30 Ea 102.01 210.30 312.31
Forced air furnace and plenum P1@2.50 Ea 62.62 99.18 161.80
Residential fuel oil storage tank P1@2.50 Ea 62.62 99.18 161.80
Steam or hot water boiler P1@2.50 Ea 101.00 99.18 200.18

Remove residential heating duct. Includes hauling components from the site. No salvage value
assumed. Costs will be higher if components include detectable friable asbestos or if access to the site
is limited. If the furnace or ductwork is wrapped in asbestos, you may be legally required to follow
asbestos abatement procedures. This may require the services of a specialized asbestos abatement
contractor. Add the cost of patching wall, floor or ceiling surfaces and the cost of closing openings after
duct is removed. Large register openings in a gravity system can be converted to cold air returns in a
forced air system. This avoids closing and patching large wall openings.
Duct runs to 30 feet, per run P1@1.50 Ea 23.53 59.51 83.04
Duct runs 30 feet to 40 feet P1@1.75 Ea 29.59 69.42 99.01
Duct runs over 40 feet P1@2.00 Ea 35.45 79.34 114.79

Gas-fired forced air furnace -- duct on interior walls. Includes a humidifier, filter, 5 to 8 galvanized
sheet metal duct runs, registers and grilles, thermostat and electrical hookup, connection to gas line
and gas piping, chimney vent and vent accessories, supply and return air plenums, system start-up and
balancing. Installed in a one- or two-story home with conventional ducting. Add for wall, floor and ceiling
patching as required.
80,000 Btu P1@42.0 Ea 2,272.50 1,666.00 3,938.50
100,000 Btu P1@43.5 Ea 2,484.60 1,726.00 4,210.60
125,000 Btu P1@45.0 Ea 2,838.10 1,785.00 4,623.10
150,000 Btu P1@47.0 Ea 3,070.40 1,864.00 4,934.40
175,000 Btu P1@49.0 Ea 3,080.50 1,944.00 5,024.50
Add for each second floor duct run P1@1.50 Ea 47.77 59.51 107.28
Add for trunk run to a room addition P1@4.00 Ea 480.76 158.70 639.46

Gas-fired forced air furnace -- duct on exterior walls (perimeter system). Includes a humidifier,
filter, 5 to 8 galvanized sheet metal duct runs, registers and grilles, thermostat and electrical hookup,
connection to gas line and gas piping, chimney vent and vent accessories, supply and return air
plenums, system start-up and balancing. Installed in a one- or two-story home with perimeter ducting.
Add for wall, floor and ceiling patching as required.
80,000 Btu P1@46.0 Ea 2,403.80 1,825.00 4,228.80
100,000 Btu P1@47.5 Ea 2,696.70 1,884.00 4,580.70
125,000 Btu P1@49.0 Ea 2,888.60 1,944.00 4,832.60
150,000 Btu P1@51.0 Ea 2,969.40 2,023.00 4,992.40
175,000 Btu P1@53.0 Ea 2,979.50 2,103.00 5,082.50
Add for each second floor duct run P1@2.00 Ea 47.77 79.34 127.11
Add for trunk run to a room addition P1@4.00 Ea 480.76 158.70 639.46

Low-boy style gas-fired forced air furnace. When vertical space is limited, install a low-headroom
gas furnace. Specs are the same as for a conventional gas furnace, but the furnace cost will be higher.
Add the following to either conventional or perimeter gas furnace costs.
Add for low-boy 80,000 Btu furnace P1@1.00 Ea 136.35 39.67 176.02
Add for low-boy 100,000 Btu furnace P1@2.00 Ea 164.63 79.34 243.97
Add for low-boy 125,000 Btu furnace P1@2.00 Ea 180.79 79.34 260.13
Add for low-boy 150,000 Btu furnace P1@4.00 Ea 240.38 158.70 399.08
